凯斯零件查询(4330) - TITAN FLOATER (6/98-8/99) (01-006[01]) - HEAT A/C GROUP (CAB) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
140 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2296337
|
[2] |
CLAMP
|
BN
H1 0SS
|
| 2. |
BN2391926
|
[1] |
SWITCH
|
BN
Air Toggle On-Off
|
| 3. |
BN2395246
|
[1] |
HYDRAULIC VALVE
|
BN
Heater Control Air
|
| 4. |
BN2399402
|
[1] |
ADAPTER
|
BN
1/8" MPT x 1/4" OD Tube, Push Lock Fitting
|
| 5. |
BN2399405
|
[2] |
90 ELBOW
|
BN
1/8" MPT x 1/4" OD Tube, Push Lock Fitting
|
| 6. |
BN2399408
|
[1] |
UNION TEE
|
BN
Tube UTC140
|
| 7. |
BN1470808
|
[2] |
NUT
|
BN
#10-32 Machine Zinc Superseded by part number: 225-14210
|
| 8. |
BN1914070
|
[2] |
SCREW,#10 - 32 x 3/4"
|
BN
#10-32 X 3/4 Machine
|
| 9. |
BN2290753
|
[1] |
GROMMET
|
BN
2870 (7/8" Hole)
|
| 10. |
BN2290763
|
[1] |
GROMMET
|
BN
2872 (1" Hole)
|
| 11. |
BN2294852
|
[5] |
O-RING
|
BN
#6 Neoprene (A/C)
|
| 12. |
BN2294854
|
[1] |
O-RING
|
BN
#8 Neoprene (A/C)
|
| 13. |
BN2294855
|
[2] |
O-RING
|
BN
#10 Neoprene (A/C)
|
| 14. |
BN2399309
|
[2] |
CLAMP
|
BN
2028
|
| 15. |
BN304325
|
[1] |
RECEIVER-DRYER
|
BN
A/C Assembly
|
| 15A. |
BN1470404C
|
[2] |
LOCK NUT
|
BN
NC 3/8-16 Flex Lock Superseded by part number: 231-4146
|
| 15B. |
BN1913634C
|
[1] |
3/8-16 X 1, HH, G8
|
|
| 15C. |
BN50368
|
[1] |
BOLT
|
BN
|
| 15D. |
BN67726
|
[1] |
CLAMP
|
BN
receiver dryer
|
| 15E. |
BN67797
|
[1] |
RECEIVER-DRYER
|
BN
|
| 16. |
BN2395298
|
[1] |
HYDRAULIC VALVE
|
BN
A/C Expansion Valve, Not Shown Superseded by part number: 47597457, 47597455
|
