凯斯零件查询(4375) - TITAN FLOATER (5/98-8/99) (10-011) - FOAM MARKER PARTS, FLEX - AIR ONLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
655 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 0. |
BN305112
|
[1] |
FOAM
|
BN
Marker Parts
|
| 1. |
BN311715
|
[2] |
PLATE
|
BN
Foam Tank Extension 6"
|
| 2. |
BN2290333
|
[1] |
LOOM
|
BN
3/8" ID #1784, 9FT
|
| 3. |
BN2290561
|
[1] |
FITTING
|
BN
2103-8-6
|
| 4. |
BN2292088
|
[21] |
AIR INTAKE TUBE
|
BN
3/8" Black Superseded by part number: 84422568
|
| 5. |
BN2393063
|
[2] |
TERMINAL
|
BN
KTN93
|
| 6. |
BN3600002-072.54
|
[1] |
Hose, Assembly, 451AR-6-01
|
|
| 7. |
88725
|
[8] |
BOLT,Hex, 3/4" - 10 x 1 3/4", Gr 5, Full Thd
|
WIN
|
| 8. |
BN50969
|
[8] |
NUT
|
BN
3/4-10, NLN, G5 Superseded by part number: 231-41412
|
| 9. |
BN55383
|
[8] |
BOLT
|
BN
Screw, Button 1/4-20 X 1/2
|
| 10. |
BN8207085
|
[1] |
WIRE HARNESS
|
BN
Foam Marker (42)
|
