凯斯零件查询(4375) - TITAN FLOATER (5/98-8/99) (07-001) - PNEUMATIC ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
819 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Air Compressor Group
|
| 8. |
BN302679
|
[1] |
Secondary Air Tank
|
|
| 9. |
BN302678
|
[1] |
Primary Air Tank
|
|
| 11. |
7148114-B
|
[1] |
MANIFOLD
|
CUR
Assembly, Air
|
| 12. |
BN302677
|
[1] |
PACKAGE
|
BN
Air Dryer
|
| 14. |
BN303957
|
[1] |
HOSE
|
BN
10-100R14-10Fjx-10Fjx-85
|
| 15. |
BN303497
|
[1] |
4-100R5-4Fjx-4Fjx-77
|
|
| 16. |
BN3600003-066.70
|
[1] |
451 AR-8-01
|
|
| 17. |
BN3600002-022.54
|
[1] |
451 AR-6-01
|
|
| 18. |
BN3600002-038.50
|
[1] |
451 AR-6-01
|
|
| 19. |
BN3600002-034.54
|
[1] |
451 AR-6-01
|
|
| 21. |
BN3600001-162.38
|
[1] |
451 AR-4-01
|
|
| 22. |
BN3600002-032.54
|
[1] |
451 AR-6-01
|
|
| 23. |
BN3600002-018.54
|
[1] |
451 AR-6-01
|
|
| 24. |
BN3600001-170.38
|
[1] |
451 AR-4-01
|
|
| 25. |
BN3600003-180.70
|
[1] |
451 AR-8-01
|
|
| 26. |
BN3600003-076.70
|
[1] |
451 AR-8-01
|
|
| 27. |
BN3600003-056.70
|
[1] |
451 AR-8-01
|
|
| 28. |
BN3600001-034.38
|
[1] |
451 AR-4-01
|
|
| 29. |
BN3600001-056.38
|
[1] |
451 AR-4-01
|
|
| 30. |
BN3600003-044.70
|
[1] |
451 AR-8-01
|
|
| 31. |
BN2292089
|
[1] |
AIR INTAKE TUBE
|
BN
Synflex, 1/4" Bulk
|
| 32. |
BN2292088
|
[1] |
AIR INTAKE TUBE
|
BN
3/8" Black Superseded by part number: 84422568
|
| 33. |
BN2393051
|
[1] |
TUBE,1/4" X 500' BULK, SAE J844, RED
|
BN
Air, Synflex 1/4" Red, Bulk
|
| 34. |
BN2393053
|
[1] |
TUBE,1/4" X 100' BULK, SAE J844, GREEN
|
BN
Air, Synflex 1/4" Green
|
| 35. |
BN303498
|
[1] |
4-100R5-4Fjx-4Fjx-90
|
|
