现代零件查询R210LC-7(#98001-) UPPER HYDRAULIC PIPING(BASE)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
826 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 3. |
31N6-11012
|
[1] |
PIPE ASSY-SUCTION
|
|
| 4. |
31N6-11021
|
[2] |
PIPE ASSY-RETURN
|
|
| 5. |
31N6-12210C
|
[1] |
PIPE SUB ASSY
|
|
| 5. |
31N6-12211
|
[1] |
PIPE SUB ASSY
|
|
| 5-1. |
31N6-11161
|
[1] |
PIPE ASSY
|
|
| 5-1. |
31N6-11162
|
[1] |
PIPE ASSY
|
|
| 5-1-1. |
X710-100106
|
[1] |
CAP-HYD,ORFS
|
|
| 5-1-2. |
S621-021001
|
[1] |
O-RING
|
|
| 5-2. |
31ER-11111
|
[1] |
VALVE-CHECK
|
|
| 5-3. |
31ER-11121
|
[1] |
VALVE-CHECK
|
|
| 5-4. |
Y172-003004
|
[2] |
O-RING
|
|
| 5-4. |
Y172-003004
|
[1] |
O-RING
|
|
| 5-5. |
S109-120456
|
[4] |
BOLT-SOCKET
|
|
| 5-5. |
S109-120456
|
[2] |
BOLT-SOCKET
|
|
| 5-6. |
S403-122006
|
[4] |
WASHER-PLAIN
|
|
| 5-6. |
S403-122006
|
[2] |
WASHER-PLAIN
|
|
| 6. |
31N6-12220
|
[1] |
PIPE SUB ASSY
|
|
| 6-1. |
31N6-12230
|
[1] |
PIPE ASSY
|
|
| 6-2. |
31ER-11111
|
[1] |
VALVE-CHECK
|
|
| 6-3. |
Y172-003004
|
[1] |
O-RING
|
|
| 6-4. |
S109-120456
|
[2] |
BOLT-SOCKET
|
|
| 6-5. |
S403-122006
|
[2] |
WASHER-PLAIN
|
|
| 7. |
S109-120406
|
[2] |
BOLT-SOCKET
|
|
| 8. |
31N6-11172
|
[1] |
PIPE ASSY
|
|
| 9. |
31N6-15200
|
[2] |
ELBOW-FLANGE
|
|
| 10. |
31N6-11081
|
[1] |
HOSE ASSY-0X90
|
|
| 11. |
31N6-11092
|
[1] |
HOSE ASSY-0X90
|
|
| 13. |
31N6-11180
|
[1] |
BRACKET-RETURN
|
|
| 30. |
P760-101030
|
[1] |
HOSE-RUBBER
|
|
| 31. |
P760-072025
|
[2] |
HOSE-RUBBER
|
|
| 31. |
31N8-13090
|
[2] |
HOSE-RUBBER
|
|
| 32. |
P760-072020
|
[2] |
HOSE-RUBBER
|
|
| 32. |
31N8-13080
|
[2] |
HOSE-RUBBER
|
|
| 34. |
31N6-11190
|
[4] |
CLAMP-HOSE WIRE TYPE
|
|
| 35. |
S572-640006
|
[16] |
CLAMP-HOSE,WIRE TYPE
|
|
| 36. |
31E5-3001
|
[2] |
CLAMP-PIPE
|
|
| 44. |
P173-160104
|
[4] |
FLANGE-HYD,SPLIT
|
|
| 46. |
S631-071001
|
[1] |
O-RING
|
|
| 47. |
S621-018001
|
[2] |
O-RING
|
|
| 48. |
Y172-006004
|
[1] |
O-RING
|
|
| 49. |
Y172-003004
|
[2] |
O-RING
|
|
| 49. |
Y172-003004
|
[3] |
O-RING
|
|
| 50. |
Y171-024004
|
[2] |
O-RING
|
|
| 51. |
Y171-019004
|
[2] |
O-RING
|
|
| 52. |
S109-100306
|
[16] |
BOLT-SOCKET
|
|
| 54. |
S109-120306
|
[8] |
BOLT-SOCKET
|
|
| 58. |
S037-123022
|
[2] |
BOLT-W/WASHER
|
|
| 60. |
S017-100952
|
[1] |
BOLT-HEX
|
|
| 65. |
S403-12100B
|
[2] |
WASHER-PLAIN
|
|
| 66. |
S403-101002
|
[2] |
WASHER-PLAIN
|
|
| 68. |
S207-101006
|
[2] |
NUT-HEX
|
|
| 72. |
S109-120256
|
[8] |
BOLT-SOCKET
|
|
| 73. |
S017-100852
|
[2] |
BOLT-HEX
|
|
| 75. |
S411-100002
|
[2] |
WASHER-SPRING
|
|
| 76. |
P174-120102
|
[2] |
FLANGE-SPLIT
|
|
| 77. |
31N7-12100
|
[2] |
FLANGE-SPLIT
|
|
