现代零件查询R210LC-7(#98001-) PILOT HYDRAULIC PIPING(BASE 1)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
321 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 7-1. |
31E5-40500
|
[2] |
SWITCH-PRESSURE
|
|
| 7-2. |
31E5-40500
|
[2] |
SWITCH-PRESSURE
|
|
| 10. |
X500-110001
|
[5] |
CONNECTOR-ORFS
|
|
| 11. |
X500-110013
|
[2] |
CONNECTOR-ORFS
|
|
| 16. |
X520-110001
|
[7] |
ELBOW-90,ORFS
|
|
| 20. |
X520-110012
|
[3] |
ELBOW-90,ORFS
|
|
| 21. |
31N4-22150
|
[1] |
TEE-LONG,ORFS
|
|
| 22. |
X820-045151
|
[4] |
TEE-R/TYPE,ORFS
|
|
| 28. |
S621-011001
|
[36] |
O-RING,ORFS
|
|
| 29. |
S631-011004
|
[18] |
O-RING
|
|
| 30. |
S631-014004
|
[6] |
O-RING
|
|
| 41. |
31E5-11110
|
[1] |
ADAPTER
|
|
| 46. |
P930-042006
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 59. |
P910-042014
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 64. |
P910-043054
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 69. |
P930-042008
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 70. |
P930-042010
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 71. |
P930-042012
|
[5] |
HOSE ASSY-ORFS 0X90
|
|
| 72. |
P930-042014
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 73. |
P930-042016
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 75. |
P930-042039
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 76. |
P930-042041
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 77. |
P930-042046
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 78. |
P930-043048
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 160. |
P930-042006
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
