凯斯零件查询(4375) - TITAN FLOATER (5/98-8/99) (05-003[02]) - REAR TIRE GROUP - 73", FIRESTONE, 16 PLY ASSY,WHEEL/TIRE RR-CS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
860 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
306896
|
[1] |
TYRE/TIRE
|
CUR
73 X 44-32 16P Fire
|
| 2. |
BN304745
|
[1] |
WHEEL
|
BN
44 X 32, 0 Offset Superseded by part number: BN311819
|
| 2A. |
BN304755
|
[1] |
O-RING,7mm Thk x 757mm ID, 65 Duro
|
BN
Superseded by part number: 87380444
|
| 2B. |
BN306434
|
[1] |
Valve Stem
|
|
| 2C. |
BN306435
|
[1] |
Valve Stem Core Housing
|
|
| 2D. |
BN304754
|
[1] |
RING
|
TYR
Lock, 32" Superseded by part number: 184472C1
|
| 2E. |
BN304753
|
[1] |
RING
|
TYR
Side, 32" X 1.70"
|
| 3. |
BN302168
|
[1] |
MUD CLEANER
|
BN
Left Rear
|
| 4. |
BN302169
|
[1] |
MUD CLEANER
|
BN
Right Rear
|
| 4A. |
BN306433
|
[3] |
CLAMP
|
BN
Flange
|
| 4B. |
BN306436
|
[6] |
BOLT
|
BN
5/8 X 1
|
