神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (755-01-1) - LIGHT INSTAL (2 LIGHT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
584 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN80E00064F1 | [1] | LIGHT | KOBInstal |
| 1. | YT80S00002F2 | [2] | LIGHT | KOBAssy (See Fig No305) Superseded by part number: YN80S00010F1 |
| 2. | YN02C01765P1 | [1] | SUPPORT | KOBPlate Assy |
| 3. | ZM27C10030 | [4] | SCREW | KOBSem |
| 4. | YN03M01159P1 | [2] | GROMMET | KOB |
| 5. | YN02C01760P1 | [2] | HARNESS | KOB |
| 6. | YN50S00040D4 | [1] | SWITCH | KOB |
| 7. | YN24S00010P1 | [1] | RELAY | KOB |
| 8. | YN02C01789P1 | [1] | PLATE | KOBAssy |
