| . . | YN02B00405F1 | [1] | BOOM | KOBInstal |
| . . | YN02B00444F1 | [1] | Boom Group | |
| 01. | YN01V00151F1 | [2] | CYLINDER | KOBAssy, Boom, Serial Range: YQ11-06001-YQ11-06505 Superseded by part number: YN01V00151F2 |
| A1. | 2444R1117D080 | [1] | HOSE,6.4mm ID x 800mm L | KOB |
| A2. | 2444R1117D084 | [1] | HOSE,6.40mm ID x 840mm L | KOB Superseded by part number: 2444R1117D085 |
| A3. | 2444R1117D260 | [1] | HOSE,6.4mm ID x 2600mm L | KOB |
| A4. | 2444R1117D270 | [1] | HOSE,6.40mm ID x 2700mm L | KOB |
| A5. | 2444R1117D440 | [1] | HOSE,6.40mm ID x 4400mm L | KOB |
| A6. | ZH32Z04000 | [2] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| A7. | ZG91S02000 | [6] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A8. | LQ02B01168P1 | [1] | LINK | KOB |
| A9. | 2419T4696 | [2] | PIN | KOB Superseded by part number: LQ02B01300P1 |
| A10. | 2419T3095 | [2] | COTTER PIN | KOB |
| . . | YN02B00435F1 | [1] | Hoe | |
| B1. | YN02B00436F1 | [1] | BOOM | KOBHoe (See Fig No. 845) |
| B2. | 2445R138D8 | [2] | SEAL,90mm ID x 105mm OD x 4mm Thk | KOBDust |
| . . | YN02B00363F1 | [1] | Instal | |
| C1. | YN02B01719P1 | [1] | PIN,90mm OD x 876mm L | KOB |
| C2. | HS18C20175G2 | [1] | BOLT,Hex, M20 x 175mm, Cl 10.9 | KOBCap Superseded by part number: 87334470 |
| C3. | ZN18C20016 | [2] | NUT | KOB |
| C4. | B16T0442D53 | [1] | SHIM,92mm ID x 160mm OD x 0.5mm Thk | KOB(0.5) |
| C5. | B16T0442D40 | [1] | SHIM,92mm ID x 160mm OD x 0.9mm Thk | KOB(0.9) |
| C6. | B16T0442D14 | [1] | SHIM,160mm OD x 92mm ID x 1.6mm Thk | KOB(1.6) |
| C7. | B16T0442D15 | [1] | SHIM,160mm OD x 92mm ID x 2.3mm Thk | KOB(2.3) |
| C8. | YN02B01414D1 | [2] | SHIM,92mm ID x 160mm OD x 2mm Thk | KOB(2.0) |
| . . | YN01V00151F2 | [2] | CYLINDER,Double Acting, 85mm Rod, 1355mm Stroke | KOBAssy, Boom, Start Serial: YQ11-06506 |
| . . | YN02B00364F1 | [1] | Instal | |
| D1. | YN02B01720P1 | [2] | PIN,85mm OD x 258mm L | KOB |
| D2. | YN02B01721P1 | [1] | PIN,85mm OD x 776mm L | KOB |
| D3. | HS18C16150G2 | [4] | SCREW | KOBCap |
| D4. | YN02B01108P1 | [2] | BOSS | KOB Superseded by part number: 72953989 |
| D5. | ZN18C16013 | [8] | NUT | KOB |
| D6. | YN02B01417D1 | [6] | SHIM,87mm ID x 140mm OD x 2mm Thk | KOB(2.0) |
| D7. | YN02B01109D1 | [1] | SHIM,87mm ID x 120mm OD x 0.5mm Thk | KOB(0.5) |
| D8. | YN02B01109D2 | [1] | SHIM,87mm ID x 120mm OD x 0.9mm Thk | KOB(0.9) |
| D9. | YN02B01109D4 | [1] | SHIM,87mm ID x 120mm OD x 1.6mm Thk | KOB(1.6) |
| D10. | B16T0442D78 | [1] | SHIM,87mm ID x 140mm OD x 0.5mm Thk | KOB(0.5) |
| D11. | B16T0442D77 | [1] | SHIM,87mm ID x 140mm OD x 0.9mm Thk | KOB(0.9) |
| D12. | B16T0442D62 | [1] | SHIM,87mm ID x 140mm OD x 1.6mm Thk | KOB(1.6) |
| . . | YN02B00477F1 | [1] | Instal | |
| 02. | YN01V00132F4 | [1] | HYDRAULIC CYLINDER | KOBAssy, Arm |
| . . | YN02B00244F1 | [1] | Instal | |
| E1. | YN02B01466P1 | [1] | PIN,85mm OD x 280mm L | KOB |
| E2. | HS18C16150G2 | [1] | SCREW | KOBCap |
| E3. | ZN18C16013 | [2] | NUT | KOB |
| E5. | B16T0442D78 | [1] | SHIM,87mm ID x 140mm OD x 0.5mm Thk | KOB(0.5) |
| E6. | B16T0442D77 | [1] | SHIM,87mm ID x 140mm OD x 0.9mm Thk | KOB(0.9) |
| E7. | B16T0442D62 | [1] | SHIM,87mm ID x 140mm OD x 1.6mm Thk | KOB(1.6) |
| E8. | YN02B01417D1 | [2] | SHIM,87mm ID x 140mm OD x 2mm Thk | KOB(2.0) |
