现代零件查询R210LC-7(#98001-) CAB ELECTRIC 2(-#8201)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
972 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
ELECRTIC CABIN
|
|
| 2. |
21N8-21011
|
[1] |
BRACKET WA
|
|
| 3. |
21N8-21070
|
[1] |
BRACKET WA
|
|
| 4. |
S035-061526
|
[5] |
BOLT-W/WASHER
|
|
| 5. |
21N8-21021
|
[1] |
COVER-WIPER MOTOR
|
|
| 6. |
S035-081526
|
[4] |
BOLT-W/WASHER
|
|
| 11. |
21N8-20010
|
[1] |
SOCKET-12V
|
|
| 17. |
21N8-20201
|
[1] |
DC-DC CONVERTER ASSY
|
|
| 18. |
21EH-30720
|
[1] |
STRAP-EARTH
|
|
| 19. |
21N8-11160
|
[1] |
HARNESS-CONSOLE,LH
|
|
| 20. |
21N8-11151
|
[1] |
HARNESS-CONSOLE,RH
|
|
| 25. |
21N8-40140
|
[1] |
HARNESS-SIDE,RH
|
|
| 27. |
S132-061676
|
[2] |
SCREW-W/WASHER
|
|
| 28. |
S132-061546
|
[1] |
SCREW-W/WASHER
|
|
| 29. |
S543-280003
|
[2] |
CLAMP-TUBE
|
|
| 30. |
21N6-20211
|
[2] |
WORK LAMP ASSY
|
|
| 30-1. |
S866-240650
|
[1] |
BULB
|
|
| 31. |
@
|
[1] |
BEACON LAMP SUB
|
|
| 31-1. |
21EK-10140
|
[1] |
LAMP-BEACON
|
|
| 31-11. |
21EK-10330
|
[1] |
BULB-H1, 70W
|
|
| 31-2. |
21N8-00581
|
[1] |
BRACKET-BEACON LAMP
|
|
| 31-3. |
21EK-20240
|
[1] |
HARNESS-BEACON LAMP
|
|
| 31-4. |
S037-102026
|
[1] |
BOLT-W/WASHER
|
|
| 31-5. |
S205-101006
|
[1] |
NUT-HEX
|
|
| 31-6. |
S131-051546
|
[1] |
SCREW-W/WASHER
|
|
| 32. |
21N8-00581
|
[1] |
BRACKET-BEACON LAMP
|
|
| 33. |
S131-051046
|
[4] |
SCREW-W/WASHER
|
|
| 34. |
S131-051546
|
[6] |
SCREW-W/WASHER
|
|
| 35. |
S037-102022
|
[9] |
BOLT-W/WASHER
|
|
| 36. |
S661-260300
|
[1] |
CAP-RUBBER
|
|
| 37. |
21M5-50250
|
[1] |
SWITCH ASSY
|
|
| 38. |
21N8-21080
|
[1] |
PLATE
|
|
| 39. |
S890-107508
|
[1] |
TUBE-PVC
|
|
| 43. |
21N4-01130
|
[6] |
PLATE-CLIP
|
|
| 44. |
25D1-10660
|
[1] |
CLIP ASSY
|
|
| 45. |
25D1-10650
|
[1] |
CLIP ASSY
|
|
| 46. |
S591-000802
|
[2] |
CLIP-HARNESS
|
|
| 47. |
S161-040106
|
[3] |
SCREW-CROSS R/ROUND
|
|
| 49. |
21N6-10450
|
[1] |
PLATE-C/RADIO COVER
|
|
| 50. |
21N8-40190
|
[1] |
EXT.HARNESS-A/RIDE SEAT
|
|
| 60. |
21N8-50010
|
[1] |
CASSETTE RADIO ASSY
|
|
| 60-1. |
21N6-10480
|
[1] |
BRACKET-LH
|
|
| 60-2. |
21N6-10490
|
[1] |
BRACKET-RH
|
|
| 60-3. |
21N8-01600
|
[1] |
HARNESS-EXT WIRE
|
|
| 60-4. |
S141-050106
|
[4] |
SCREW-FLAT HD
|
|
| 61. |
21N8-40500
|
[1] |
CD PLAYER ASSY
|
|
| 61-1. |
21N6-10480
|
[1] |
BRACKET-LH
|
|
| 61-2. |
21N6-10490
|
[1] |
BRACKET-RH
|
|
| 61-3. |
21N8-01600
|
[1] |
HARNESS-EXT WIRE
|
|
| 61-4. |
S141-050106
|
[4] |
SCREW-FLAT HD
|
|
| 62. |
21N8-40940
|
[1] |
COVER-DUST
|
|
