| . . | YN42H00342F1 | [1] | Hyd, Boom | |
| A1. | YN42H02607P2 | [1] | TUBE,27.2 mm OD | KOBHYD. TUBE |
| A2. | YN42H02608P1 | [1] | TUBE,27.2 mm OD | KOBHYD. TUBE |
| A3. | YN42H02609P1 | [1] | TUBE,27.2 mm OD | KOBHYD. TUBE |
| A4. | YN42H02610P1 | [1] | TUBE,34.0 mm OD | KOBHYD. TUBE |
| A5. | YN42H01998P1 | [1] | TUBE,27.2 mm OD x 4943, 114 mm Length | KOB |
| A6. | YN42H01999P1 | [1] | TUBE | KOB Superseded by part number: YN42H02909P1 |
| A7. | YN42H02348P1 | [2] | CLAMP | KOB |
| A8. | YN42H02351P1 | [2] | CLAMP | KOB Superseded by part number: 84528894 |
| A9. | ZC36X28014 | [4] | CLAMP | KOB |
| A10. | 2432T2434 | [4] | CLAMP | KOB |
| A11. | ZC26X28014 | [4] | CLAMP | KOB |
| A12. | YN42H02319P1 | [3] | BUSHING,27.2mm ID x 34mm OD x 83mm L | SM Superseded by part number: 84354627 |
| A13. | YN43H01524P1 | [1] | BUSHING,34mm ID x 53mm OD x 83mm L | KOB Superseded by part number: 84354629 |
| A14. | ZD12A01800 | [5] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| A15. | ZD12A02100 | [5] | O-RING | KOB |
| A16. | ZM73C12035 | [4] | BOLT,M12x35mm - Course Thread | KOBSems |
| A17. | ZS18C12055 | [12] | SCREW,Hex, M12 x 55mm | KOBCap |
| A18. | ZW16H12000 | [12] | WASHER | KOB |
| . . | YN42H00352F1 | [1] | Hyd, Cylinder | |
| . . | YN42H00298F1 | [1] | Hyd, Cylinder | |
| B1. | YN42H02341P1 | [1] | TUBE | KOB |
| B2. | ZX20H10072 | [2] | HOSE | KOB |
| B3. | ZX20H16078 | [2] | HOSE | KOB |
| B4. | YN42H02615P1 | [2] | BAND | KOB |
| B5. | YX42H01074P2 | [2] | BAND | KOB |
| B6. | YY42H01184P1 | [2] | CLAMP | KOB |
| B7. | ZH22Z04000 | [2] | HYD CONNECTOR | KOB |
| B8. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| B9. | ZD12P02600 | [1] | O-RING | KOB |
| B10. | ZD12A01600 | [1] | O-RING | KOB |
| B11. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBCap |
| B12. | ZS18C12065 | [2] | SCREW,Hex, M12 x 65mm | KOBCap |
| B13. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBCap |
| B14. | ZW26X10000 | [4] | LOCK WASHER | KOB |
| B15. | ZW16H12000 | [2] | WASHER | KOB |
| . . | YN42H00331F1 | [1] | KIT | KOBHyd, Cylinder |
| C1. | YN42H02342P1 | [1] | TUBE,21.7 mm OD x 1211, 244 mm Length | KOB |
| C2. | ZD12P02600 | [1] | O-RING | KOB |
| C3. | ZD12A01600 | [1] | O-RING | KOB |
| C4. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBCap |
| . . | YN42H00300F1 | [1] | Hyd, Cylinder | |
| D1. | YN42H02618P1 | [1] | TUBE | KOB |
| D2. | YN42H02619P1 | [1] | TUBE,34.0 mm OD | KOB |
| D3. | HX20L04110DX | [1] | HOSE,6.3mm ID x 1100mm L | KOB |
| D4. | 2420R537D105 | [1] | HOSE,9.53mm ID x 1050mm L | KOB |
| D5. | 2420R537D110 | [1] | HOSE ASSY.,9.60mm ID x 1100mm L | KOB Superseded by part number: HX21E06110DX |
| D6. | YN28V00019F1 | [2] | VALVE | KOBAssy, Holding Superseded by part number: YN28V00023F1 |
| D7. | ZH22X06000 | [2] | HYD CONNECTOR | KOB |
| D8. | HG23F04004G1 | [2] | HYD CONNECTOR | KOB |
| D9. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow |
| D10. | HH35X06006G3 | [2] | ELBOW | KOB |
| D11. | 2444Z3155 | [2] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB Superseded by part number: YT42H01128P1 |
| D12. | HH55Q06006G1 | [2] | TEE | KOB |
| D13. | ZD12P03400 | [4] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB |
| D14. | ZD12A02100 | [2] | O-RING | KOB |
| D15. | YY42H01330P1 | [2] | O-RING,0.07" Thk x 0.301" ID, -11, Cl 5, 75 Duro | KOB |
| D17. | ZS28C12040 | [8] | SCREW,Hex Socket Head, M12 x 40mm | KOBCap |
| D18. | ZS28C12075 | [8] | SCREW,Hex Socket Head, M12 x 75mm | KOBCap |
| D19. | ZW26K12000 | [8] | LOCK WASHER | KOB |
| D20. | PY01P01043D3 | [8] | CABLE TIE,188mm L | KOB |
| . . | YN42H00225F1 | [1] | Hyd, Cylinder | |
| E1. | YN42H01951P1 | [1] | TUBE,27.2 mm OD x 1746, 131 mm Length | KOB |
| E2. | YN42H01934D1 | [1] | HOSE | KOB |
| E3. | YN02B01030D1 | [1] | HYDRAULIC HOSE | KOB |
| E4. | YN43H01097P1 | [1] | CLAMP | KOB |
| E5. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB |
| E6. | ZE13X16000 | [2] | FLANGE | KOBClamp, Half |
| E7. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| E8. | ZS28C12040 | [8] | SCREW,Hex Socket Head, M12 x 40mm | KOBCap |
| E9. | ZS18C12055 | [1] | SCREW,Hex, M12 x 55mm | KOBCap |
| E10. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB |
| E11. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| E12. | ZW26K12000 | [4] | LOCK WASHER | KOB |
| E13. | ZW26X12000 | [1] | LOCK WASHER | KOB |
