神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (860-86-1) - ARM GROUP 2.4M (7FT 11IN) (AUTO GREASTER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
615 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN12B00840F1 | [1] | Arm Group | |
| . . | YN12B00655F1 | [1] | Arm Group [ See fig No. 860 ] | |
| . . | YN12B00887F1 | [1] | Arm Group (nibbler & Breaker) | |
| . . | YN12B00880F1 | [1] | Arm Group [See fig no. 580-60 ] | |
| . . | YN12B00729F1 | [1] | Arm Group | |
| 1. | 2479P2281D3 | [1] | DISTRIBUTOR | KOBAssy |
| 1-1. | 2479P2281S1 | [3] | ELEMENT | KOBKit |
| 1-4. | 2479P2281S4 | [1] | BOLT | KOBAssy |
| 1-7. | 2479P2281S7 | [3] | CAP | KOBCap |
| 1-8. | ZD12P01090 | [4] | O-RING | KOB |
| 2. | ZX35M06175 | [1] | HOSE | KOBHose |
| 3. | 2420R349D088 | [1] | HOSE,6.30 mm ID x 880.00 mm | KOB Superseded by part number: 2420R349D090 |
| 4. | 2420R349D094 | [1] | HOSE | KOB[ B ], Serial Range: YQ11-06001-YQ11-06562 |
| . . | 2420R349D096 | [1] | HOSE | KOB, Start Serial: YQ11-06563 Superseded by part number: HX21E04096DX |
| 5. | 2420R349D100 | [1] | HOSE | KOBHose Superseded by part number: HX21E04100DX |
| 6. | LC12B01521P1 | [1] | COVER | KOB |
| 7. | ZH22Z06000 | [1] | CONNECTION | KOB |
| 8. | 2444Z2002 | [4] | HYD CONNECTOR | KOB |
| 9. | ZH32Z04002 | [1] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| 10. | ZH42Z04000 | [1] | ELBOW | KOB |
| 11. | 2444T4678 | [3] | LUBE NIPPLE | KOB |
| 12. | ZE82T06000 | [1] | PLUG | KOB |
| 13. | LC12B01523P1 | [1] | PLATE | KOBPlate |
| 14. | ZC46X10009 | [3] | CLIP,10.1mm | KOB |
| 15. | ZM73C08016 | [2] | BOLT,M8x16mm - Course Thread | KOBSems |
| 16. | ZS18C08050 | [2] | SCREW,Hex, M8 x 50mm | KOBCap |
| 17. | ZS18C08080 | [4] | SCREW,Hex, M8 x 80mm | KOBCap |
| 18. | ZN18C06005 | [3] | NUT | KOB |
| 19. | ZW26X06000 | [3] | LOCK WASHER | KOB |
| 20. | ZW16P06000 | [3] | WASHER | KOB |
| 21. | PY01P01043D3 | [3] | CABLE TIE,188mm L | KOB |
| 22. | 2418R676D8 | [1] | TUBE | KOB |
| 23. | 2418R676D4 | [2] | TUBE | KOB |
| 24. | ZW16H08000 | [6] | WASHER | KOB |
