神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (865-01-1) - ARM ASSY, SHORT 2. 4M (7FT 11IN) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
663 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN12B00817F1 | [1] | Short 2.4 m | |
| 1. | YN12B00724F1 | [1] | ARM | KOBShort |
| 1-1. | NSS | [1] | NOT SOLD SEPARAT | CONArm, Short |
| 1-2. | YN12B02285P1 | [2] | BUSHING,89mm ID x 130mm OD x 100mm L | KOB |
| 1-3. | YN12B01943P1 | [2] | BUSHING,80mm ID x 95mm OD x 89mm L | KOB |
| 1-4. | YN12B02102P1 | [2] | BUSHING,70mm ID x 85mm OD x 69mm L | KOB |
| 1-5. | YN12B02137P1 | [2] | BUSHING,90mm ID x 105mm OD x 89mm L | KOB |
| 2. | YN12B00726P1 | [1] | Short | |
| 2-1. | YN12B02417P1 | [2] | BLOCK | KOBTapped |
| 2-2. | YN12B02026P1 | [2] | BLOCK | KOBTapped |
