凯斯零件查询(4375) - TITAN FLOATER (5/98-8/99) (01-005) - AIR CONDITIONER GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
760 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN300033
|
[1] |
CONDENSER
|
BN
AC 6 X 36
|
| 2. |
BN302694
|
[1] |
BRACKET
|
BN
A/C Condensor, RH
|
| 3. |
BN302693
|
[1] |
BRACKET
|
BN
A/C Condensor, LH
|
| 4. |
BN301011
|
[4] |
NUT
|
BN
M6-1 X 12, HH, 10.9
|
| 5. |
BN300394
|
[4] |
BOLT
|
BN
Hex, M14 x 60, 8.8, Full Thd
|
| 6. |
628-8020
|
[2] |
BOLT,Hex, M8 x 20, 10.9, Full Thd
|
CAS
Superseded by part number: 87015744
|
| 7. |
BN300429
|
[2] |
BOLT
|
BN
M8-1.25, FLN, 8.8
|
| 8. |
BN300497
|
[4] |
WASHER,M8, 10.9
|
BN
Superseded by part number: 896-15008
|
| 9. |
BN304066
|
[1] |
HOSE
|
BN
6-J51-6Fton90-6Fton90-98
|
| 10. |
BN304068
|
[1] |
HOSE
|
BN
8-J51-8Fton90-8Fton134Sp90-70
|
| 11. |
BN300393
|
[6] |
NUT
|
BN
M10-1.5, FLN, 10.9 Superseded by part number: 100037
|
| 12. |
BN300499
|
[12] |
WASHER,M10, 10.9
|
BN
Superseded by part number: 896-11010
|
| 13. |
BN302472
|
[6] |
FITTING
|
BN
M10-1.5 X 40, HH, 10.9
|
| 14. |
BN67797
|
[1] |
RECEIVER-DRYER
|
BN
|
| 14A. |
BN67726
|
[1] |
CLAMP
|
BN
receiver dryer
|
| 14B. |
BN1913634C
|
[1] |
3/8-16 X 1, HH, G8
|
|
| 14C. |
BN50368
|
[1] |
BOLT
|
BN
3/8-16 X 1.25, HH, G8
|
| 14D. |
BN1470404C
|
[2] |
LOCK NUT
|
BN
NC 3/8-16 Flex Lock Superseded by part number: 231-4146
|
| 15. |
BN304065
|
[1] |
HOSE
|
BN
6-J51-6Fton-6Fton90-17
|
| 16. |
BN304064
|
[1] |
HOSE
|
BN
6-J51-6Fton-6Mbkhd-71
|
| 17. |
BN304063
|
[1] |
HOSE
|
BN
10-J51 -10Fton45-10Mbkh-75
|
| 18. |
BN2403360
|
[1] |
EVAPORATOR
|
BN
Superseded by part number: BN309767
|
| 19. |
BN2450312
|
[1] |
AIRCOND. COMPRESSOR,W/ Pulley
|
BN
A/C SD-709
|
| 20. |
BN304067
|
[1] |
HOSE
|
BN
10-J51 -10Fton90-10Fton134Sp90-68
|
| 21. |
BN2395298
|
[1] |
HYDRAULIC VALVE
|
BN
Expansion Superseded by part number: 47597457, 47597455
|
| 21A. |
BN2294852
|
[5] |
O-RING
|
BN
#6 Neoprene (A/C)
|
| 21B. |
BN2294854
|
[2] |
O-RING
|
BN
#8 Neoprene (A/C)
|
| 21C. |
BN2294855
|
[3] |
O-RING
|
BN
#10 Neoprene (A/C)
|
