神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (900-01-1) - CAP ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
542 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN02B01737F1 | [1] | | |
| A2. | PV02B01073D3 | [2] | CAP | KOB, Serial Range: YQ11-06001-YQ11-06178 Superseded by part number: YN64H01391D1 |
| . . | YN02B01825F1 | [1] | | |
| . . | YN64H01391D1 | [2] | CAP | KOB, Start Serial: YQ11-47081 |
| . . | YN12B02301F1 | [1] | | |
| B1. | PV02B01073D4 | [1] | CAP | KOB, Serial Range: YQ11-06001-YQ11-06178 Superseded by part number: YN64H01393D1 |
| . . | YN64H01393D1 | [1] | CAP | KOB, Start Serial: YQ11-06179 |
| . . | YN12B02300F1 | [1] | | |
| D1. | PV02B01073D3 | [8] | CAP | KOB, Serial Range: YQ11-06001-YQ11-06178 Superseded by part number: YN64H01391D1 |
| D2. | PV02B01073D7 | [4] | CAP | KOB, Serial Range: YQ11-06001-YQ11-06178 Superseded by part number: YN64H01392D1 |
| . . | YN64H01392D1 | [4] | CAP | KOB, Serial Range: YN11-45001-YN11-47080 |
| . . | YN02B01738F1 | [1] | | |
| E1. | PV02B01073D4 | [2] | CAP | KOB, Serial Range: YQ11-06001-YQ11-06178 Superseded by part number: YN64H01393D1 |
| . . | YN12B02331F1 | [1] | | |
| F1. | YN64H01391D1 | [4] | CAP | KOB |
| F2. | YN64H01392D1 | [4] | CAP | KOB |
