久保田零件查询M20700 LEVER GUIDE HOOD/BONNETEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
598 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
6C12052100
|
[1] |
ASSY GUIDE LEVER LH
|
0.8140(lbs); 0.370
|
| 020. |
6C12047300
|
[1] |
LABEL MID PTO
|
0.0022(lbs); 0.001
|
| 030. |
6C12047320
|
[1] |
LABEL PTO
|
0.0022(lbs); 0.001
|
| 040. |
6C12047330
|
[1] |
LABEL RANGE SHIFT
|
0.0022(lbs); 0.001
|
| 045. |
6C12047390
|
[1] |
LABEL GUIDE
|
0.0022(lbs); 0.001
|
| 050. |
6C16052190
|
[1] |
ASSY GUIDE LEVER RH
|
0.9240(lbs); 0.420
|
| 060. |
6C19047350
|
[1] |
LABEL HYDRAULIC
|
0.0022(lbs); 0.001
|
| 070. |
6C04047362
|
[1] |
LABEL 4WD
|
0.0022(lbs); 0.001
|
| 080. |
6C04047382
|
[1] |
LABEL GUIDE
|
0.0022(lbs); 0.001
|
| 090. |
6C04047392
|
[1] |
LABEL GUIDE
|
0.0022(lbs); 0.001
|
| 100. |
6C19052140
|
[1] |
HOLDER HYD.LEVER UP
|
0.0374(lbs); 0.017
|
| 110. |
6C19052160
|
[1] |
HOLDER HYD.LEVER DO.
|
0.0374(lbs); 0.017
|
| 120. |
3135118790
|
[2] |
BOLT FLANGE
|
0.0110(lbs); 0.005
|
| 130. |
3135118860
|
[2] |
WASHER
|
0.0044(lbs); 0.002
|
| 140. |
0102550612
|
[8] |
BOLT
|
0.0110(lbs); 0.005
|
