神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (960-01-2) - NAME PLATE INSTAL (CAB) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
370 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN22T00300F6 | [1] | Name Plate Instal (Kobelco Emblem) | |
| 1. | YN20T01783P2 | [1] | LABEL | KOB |
| 2. | PH20T01018P1 | [2] | WARNING DECAL | KOB, Serial Range: YN11-45001-YN11-48664 |
| 3. | YN20T01407P1 | [1] | LABEL | KOB |
| 4. | YT20T01036P2 | [1] | LABEL | KOB |
| 5. | YN20T01408P1 | [1] | LABEL | KOB |
| 6. | YN20T01862P1 | [1] | LABEL | KOB |
| 7. | ZL11H03708 | [1] | LABEL | KOB |
| 8. | ZL11V03704 | [1] | LABEL | KOB |
| 9. | YT20T01126P1 | [1] | LABEL | KOB |
| 10. | YN20T01673P1 | [1] | LABEL | KOB |
| 11. | YN20T01784P1 | [1] | LABEL | KOB |
| 12. | ZL11H06008 | [1] | LABEL | KOB |
| 13. | YN20T01799P1 | [1] | LABEL | KOB |
| 14. | YN20T01800P1 | [1] | LABEL | KOB |
| 15. | YN20T01579P1 | [1] | LABEL | KOB |
| 20. | YN20T01886P1 | [1] | LABEL | KOB |
| 21. | YN20T01918P1 | [1] | | |
| 22. | YN20T01920P1 | [1] | | |
| 23. | YN20T01124P1 | [1] | | |
| . . | YN22T00300F5 | [1] | Name Plate Instal opt (Auto Greaser) | |
| 24. | YN20T01641P1 | [1] | | |
| 25. | LC91Z00006P1 | [1] | Operators | |
| . . | YN22T00300F1 | [1] | Name Plate Instal required (Warning) | |
| 26. | YN20T01924P1 | [1] | | |
| . . | YN22T00300F7 | [1] | Name Plate Instal (Special Purpose) | |
| 27. | YN20T01949P1 | [1] | | |
| . . | YN22T00300F8 | [1] | Name Plate Instal opt (2 Position), Start Serial: YQ11-06259 | |
| . . | PH20T01018P1 | [1] | WARNING DECAL | KOB, Start Serial: YQ11-06326 |
| 28. | LC20T01212P2 | [1] | | |
| . . | YN22T00300F4 | [1] | Name Plate Instal opt (Long Range) | |
