凯斯零件查询(FLX3010) - FLOATER (8/04-8/06) (04-023) - AIR SCREEN GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
922 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
342420A1
|
[1] |
SCREEN
|
BN
Air, Sealed
|
| 2. |
BN325817
|
[1] |
SEAL
|
BN
Foam, CAC/Hood
|
| 3. |
342289A1
|
[1] |
PLATE
|
BN
Rear Panel
|
| 4. |
86986473
|
[1] |
SCREEN
|
BN
CS
|
| 5. |
86986474
|
[1] |
SCREEN
|
BN
RS
|
| 6. |
86624184
|
[14] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 7. |
16043224
|
[3] |
BOLT,Hex, M8 x 16mm, Cl 8.8
|
NH
|
| 8. |
NS
|
[2] |
NOT SERVICED
|
BAS
Screen Side
|
| 12. |
86980380
|
[6] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
BN
|
| 13. |
120104
|
[5] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 14. |
86986477
|
[2] |
FOAM
|
BN
Lower Screen
|
| 15. |
86986478
|
[2] |
FOAM
|
BN
Screen, Lower
|
| 16. |
86986479
|
[2] |
SEAL
|
BN
Seal, Clip On
|
