神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (HC300-01-1) - MOTOR ASSY (SWING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
667 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN15V00035F1 | [1] | HYDRAULIC MOTOR | SMAssy (Swing) Superseded by part number: YN15V00055F1 |
| 51. | YN22V00014FA | [2] | VALVE | KOBAssy, Relief (See HC325) |
| 52. | YN20V00004F1 | [1] | VALVE | KOBAssy, Swing-reactionless (See HC315) |
| 101. | YN15V00025S101 | [1] | SHAFT | KOB |
| 111. | YN15V00025S111 | [1] | CYLINDER | KOB |
| 114. | YN15V00025S114 | [1] | SPRING | KOB |
| 121. | NSS | [9] | NOT SOLD SEPARAT | CONPiston |
| 122. | NSS | [9] | NOT SOLD SEPARAT | CONShoe |
| 123. | YN15V00025S123 | [1] | PLATE | KOBSet |
| 124. | YN15V00025S124 | [1] | PLATE | KOBShoe |
| 131. | YN15V00025S131 | [1] | PLATE | KOBValve |
| 301. | YN15V00035S301 | [1] | BOX | SMCase |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONCase |
| 351. | YN15V00025S351 | [2] | SPOOL | KOBPlunger |
| 355. | YN15V00002S355 | [2] | SPRING | KOB |
| 390. | YB15V00003S390 | [1] | PLATE | KOBName Plate not serviced |
| 391. | 2437U407S983 | [2] | RIVET | KOBPin |
| 401. | ZS23C20045 | [4] | CAP,Hex Socket Head, M20 x 45mm | KOB |
| 443. | YN15V00002S011 | [1] | ROLLER BEARING | KOBRoller |
| 444. | LQ15V00008S010 | [1] | ROLLER BEARING | KOBRoller |
| 451. | NSS | [2] | NOT SOLD SEPARAT | CONPin |
| 469. | YN15V00002S012 | [2] | PLUG | KOB |
| 472. | YN15V00025S489 | [1] | O-RING,3.5mm Thk x 173mm ID, 75 Duro | KOB |
| 488. | ZD12P02800 | [2] | O-RING | KOB |
| 491. | YN15V00035S491 | [1] | OIL SEAL | SMOil Seal |
| 702. | YN15V00002S014 | [1] | PISTON | KOBBrake |
| 706. | 2441U736S706 | [1] | O-RING | KOB |
| 707. | 2415U188S707 | [1] | O-RING | KOB |
| 712. | YN15V00025S712 | [18] | SPRING,ID1.1mm : OD1.8mm : W=3.7mm (this is spring) | KOB |
| 742. | YN15V00025S742 | [3] | PLATE,ID14mm : OD15.5mm : W=1.7mm | KOBFriction |
| 743. | YN15V00025S743 | [4] | PLATE,ID14mm : OD15.5mm : W=2mm | KOBSeparator |
| 980. | YN15V00035S980 | [1] | PLUG | SM |
| 984. | YN15V00035S984 | [1] | PLUG | SM |
| 985. | YN15V00035S985 | [3] | PLUG | SM |
| 993. | ZE82T08000 | [1] | PLUG | KOB |
| 994. | ZE82T12000 | [1] | PLUG | KOB |
| . . | YN15V00025R100 | [1] | REPAIR KIT | KOBConsists Of Ref. 121x9, 122x9 |
| . . | YN15V00025R200 | [1] | REPAIR KIT | KOBConsists Of Ref. 303x1, 451x2 |
| . . | YM15V00006R100 | [1] | KIT | SMRepair Consists Of Ref. 472x1, 488x2, 491x1 |
