神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (HC405-01-2[2]) - PUMP, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
589 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN10V00043F1 | [1] | HYDRAULIC PUMP | SMAssy |
| 111. | YN10V00043S111 | [1] | SHAFT | SM |
| 113. | YN10V00013S113 | [1] | SHAFT | KOB |
| 116. | YN10V00020S116 | [1] | GEAR | KOB |
| 123. | LC10V00002S123 | [2] | BEARING | KOBRoller |
| 124. | YN10V00011S124 | [2] | NEEDLE BEARING | KOBNeedle |
| 127. | 2441U723S127 | [4] | SPACER | KOB |
| 141. | NSS | [2] | NOT SOLD SEPARAT | CONBlock, Cylinder |
| 151. | NSS | [18] | NOT SOLD SEPARAT | CONPiston |
| 152. | NSS | [18] | NOT SOLD SEPARAT | CONShoe |
| 153. | 2437U213S153 | [2] | PLATE | KOB Superseded by part number: LC10V00010S153 |
| 156. | YN10V00005S156 | [2] | BUSHING | KOB |
| 157. | 2437U213S157 | [18] | SPRING | KOB |
| 211. | 2441U242S211 | [2] | PLATE | KOBShoe |
| 212. | NSS | [2] | NOT SOLD SEPARAT | CONPlate |
| 214. | NSS | [2] | NOT SOLD SEPARAT | CONBushing |
| 251. | 2437U213S251 | [2] | PLATE | KOBSupport |
| 261. | 2437U420S261 | [1] | COVER | KOBSeal |
| 271. | YN10V00043S271 | [2] | BOX | SMCase |
| 312. | LC10V00010S312 | [1] | BLOCK | SMValve |
| 313. | NSS | [1] | NOT SOLD SEPARAT | CONPlate, Valve |
| 314. | NSS | [1] | NOT SOLD SEPARAT | CONPlate, Valve |
| 325. | YN10V00043S325 | [1] | COVER | SM |
| 401. | 2437U213S401 | [8] | SCREW | KOBCap |
| 406. | ZS23C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOBCap |
| 407. | ZS23C06055 | [3] | CAPSCREW,Hex Socket Head, M6 x 55mm | KOBSCREW Cap |
| 466. | 2441U667S466 | [2] | PLUG | KOB |
| 467. | 2441U549S464 | [2] | PLUG | KOB |
| 468. | 2441U436S469 | [4] | PLUG | KOB |
| 490. | 2441U722S490 | [32] | PLUG | KOB |
| 531. | NSS | [2] | NOT SOLD SEPARAT | CONPin |
| 532. | 2437U213S532 | [2] | PISTON | KOB |
| 534. | 2437U213S534 | [2] | STOP | KOBStopper |
| 535. | 2437U213S535 | [2] | STOP | KOBStopper |
| 546. | YN10V00043S546 | [2] | SPACER | SM |
| 548. | NSS | [2] | NOT SOLD SEPARAT | CONPin, Feedback |
| 702. | YN10V00003S702 | [2] | O-RING | KOBO-ring |
| 710. | YX10V00003S012 | [2] | O-RING | KOB |
| 717. | YN10V00020S012 | [4] | O-RING,3.1mm Thk x 144.4mm ID, 70 Duro | KOB |
| 724. | YX10V00003S015 | [16] | O-RING,1.9mm Thk x 8.8mm ID, 75 Duro | KOB |
| 725. | YT10V00003S710 | [9] | O-RING | KOB |
| 727. | YN10V01001S727 | [3] | O-RING | KOBO-Ring |
| 728. | YN10V00020S015 | [4] | O-RING | KOB |
| 732. | YT10V00003S708 | [2] | O-RING | KOB |
| 774. | YN10V00032S775 | [1] | OIL SEAL | KOB Superseded by part number: EG10V00004S774 |
| 789. | ZD85P01800 | [2] | RING | KOBBack Up |
| 792. | ZD85G03500 | [2] | RING | KOBBack Up |
| 806. | ZN18C16010 | [2] | NUT | KOB |
| 808. | ZN18C20012 | [2] | NUT | KOB |
| 824. | ZR16X04000 | [2] | RING | KOBRetaining |
| 885. | 2441U723S885 | [2] | PIN | KOB |
| 886. | ZP26D06014 | [4] | PIN | KOBSpring |
| 901. | ZS91C01000 | [2] | BOLT | KOBEye |
| 953. | 2437U188S953 | [2] | CAP,M10 x 20mm | KOBSetscrew |
| 954. | 2437U213S954 | [2] | SCREW | KOBSetscrew |
| 981. | YB15V00003S390 | [1] | PLATE | KOB |
| 983. | 2437U407S983 | [2] | RIVET | KOBPin |
| . . | YN10V00003S011 | [1] | PISTON ASSY | KOBRepair Kit Consists Of Ref. 151x9, 152x9 |
| . . | YN10V00043R100 | [1] | REPAIR KIT | KOBRepair Kit Consists Of Ref. 141x1, 313x1 |
| . . | YN10V00043R200 | [1] | REPAIR KIT | KOBRepair Kit Consists Of Ref. 141x1, 314x1 |
| . . | 2437U213S30 | [1] | REPAIR KIT | KOBRepair Kit Consists Of Ref. 212x1, 214x1 |
| . . | 2437U213S530 | [1] | REPAIR KIT | KOBRepair Kit Consists Of Ref. 531x1, 548x1 |
