神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (HC933-49-1) - JOINT ASSY, SWIVEL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
426 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN55V00019F1 | [1] | Swivel | |
| . . | YN55V00019F2 | [1] | Swivel | |
| . . | YN55V00019F3 | [1] | Swivel | |
| 1. | YN55V01033P1 | [1] | Body | |
| 2. | YN55V01035P1 | [1] | Stem (F2 ONLY) | |
| 3. | 2414T2712 | [1] | PIVOT | KOBPlate, Thrust |
| 4. | 2414P6082 | [1] | COVER | KOB |
| 5. | 2445Z917 | [9] | SEAL | KOBSeal Assy |
| 6. | ZD11P11000 | [2] | SEAL,109.6mm ID x 120mm OD x 5.2mm Thk | KOBO-Ring |
| 7. | ZD11G12500 | [1] | O-RING,3.1mm Thk x 124.4mm ID, 70 Duro | KOBO-Ring |
| 8. | ZS23C08020 | [2] | SCREW,Hex Socket Head, M8 x 20mm | KOBCap |
| 9. | ZS23C08030 | [4] | SCREW,Hex Socket Head, M8 x 30mm | KOBCap Superseded by part number: ZS28C08030 |
| 11. | 2420Z1036D3 | [2] | CLEVIS | KOB |
| 12. | ZE82T08000 | [2] | PLUG | KOB |
| 13. | ZE82T06000 | [1] | PLUG | KOB |
| 14. | ZE82T04000 | [2] | PLUG | KOB |
| 15. | YN55V01036P1 | [1] | (F2, F3 ONLY) | |
| 16. | YN55V01037P1 | [2] | (F2, F3 ONLY) | |
| 17. | YN55V01038P1 | [1] | (F2, F3 ONLY) | |
| 18. | YN55V01041P1 | [1] | (F1 ONLY) | |
| 19. | YN22T00194P1 | [1] | TYPE PLATE | KOBName |
| 20. | YY55V01003P1 | [1] | (F3 ONLY) | |
