现代零件查询R210LC-7H(#9001-) TRAVEL MOTOREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
987 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31N6-40060
|
[1] |
TRAVEL MOTOR ASSY
|
|
| . |
31N6-40060BG
|
[1] |
TRAVEL MOTOR ASSY
|
|
| N -1. |
XKAH-01043
|
[1] |
MOTOR DEVICE
|
|
| -11. |
XKAH-00891
|
[1] |
C/BLOCK & PISTON KIT
|
|
| 104. |
XKAH-01044
|
[2] |
BLOCK-CYLINDER
|
|
| 110. |
XKAH-00407
|
[2] |
WASHER
|
|
| 114. |
XKAH-00406
|
[1] |
SPRING
|
|
| 145. |
XKAH-00405
|
[1] |
RING-SNAP
|
|
| -12. |
XKAH-00893
|
[1] |
PISTON ASSY
|
|
| N105. |
XKAH-01045
|
[9] |
PISTON
|
|
| N106. |
XKAH-00419
|
[9] |
SHOE
|
|
| 151. |
XKAH-00404
|
[6] |
ROLLER
|
|
| 107. |
XKAH-00403
|
[1] |
PLATE-RETAINER
|
|
| 108. |
XKAH-00402
|
[1] |
BALL-THRUST
|
|
| -13. |
XKAH-00895
|
[1] |
PISTON ASSY
|
|
| N161. |
XKAH-00422
|
[1] |
PISTON
|
|
| N162. |
XKAH-00421
|
[1] |
SHOE
|
|
| 163. |
XKAH-00094
|
[1] |
SPRING
|
|
| 102. |
XKAH-00410
|
[1] |
SHAFT-MAIN
|
|
| 103. |
XKAH-01046
|
[1] |
PLATE-SWASH
|
|
| 109. |
XKAH-00897
|
[1] |
PLATE-TIMING
|
|
| 115. |
XKAH-00399
|
[3] |
PLATE-FRICTION
|
|
| 116. |
XKAH-00401
|
[4] |
PLATE-MATING
|
|
| 112. |
XKAH-00898
|
[1] |
PISTON-PARKING
|
|
| 113. |
XKAH-00397
|
[9] |
SPRING
|
|
| 132. |
XKAH-00388
|
[1] |
OIL SEAL
|
|
| 149. |
XKAH-00899
|
[1] |
SLEEVE ASSY
|
|
| 150. |
XKAH-00900
|
[1] |
BEARING-BALL
|
|
| 139. |
XKAH-00396
|
[1] |
O-RING
|
|
| 178. |
XKAH-00395
|
[1] |
O-RING
|
|
| 181. |
XKAH-00377
|
[2] |
PIN-PARALLEL
|
|
| 167. |
XKAH-00095
|
[2] |
PIVOT
|
|
| 168. |
XKAH-00034
|
[2] |
PIN-PARALLEL
|
|
| -21. |
XKAH-01065
|
[1] |
RELIEF VALVE ASSY
|
|
| N301. |
XKAH-01066
|
[1] |
SEAT
|
|
| N302. |
XKAH-01064
|
[1] |
PLUNGER
|
|
| N303. |
XKAH-01063
|
[1] |
ROD
|
|
| N304. |
XKAH-00668
|
[1] |
PISTON
|
|
| N305. |
XKAH-00670
|
[1] |
BODY
|
|
| N306. |
XKAH-01062
|
[1] |
PLUG
|
|
| N307. |
XKAH-00671
|
[1] |
SPRING
|
|
| N308. |
XKAH-00669
|
[1] |
SHIM
|
|
| 309. |
XKAH-00035
|
[1] |
O-RING
|
|
| 310. |
XKAH-00035
|
[1] |
O-RING
|
|
| 311. |
XKAH-00665
|
[1] |
RING-BACK UP
|
|
| -3. |
XKAH-01035
|
[1] |
REAR FLANGE ASSY
|
|
| -31. |
XKAH-01036
|
[1] |
REAR FLANGE KIT
|
|
| 201. |
XKAH-01037
|
[1] |
REAR FLANGE
|
|
| 223. |
XKAH-01038
|
[1] |
MAIN SPOOL
|
|
| -32. |
XKAH-00874
|
[2] |
STOPPER ASSY
|
|
| N294. |
XKAH-00875
|
[1] |
STOPPER-A
|
|
| N298. |
XKAH-00876
|
[1] |
STOPPER-B
|
|
| N295. |
XKAH-01052
|
[1] |
SPOOL
|
|
| N296. |
XKAH-01040
|
[1] |
SPRING
|
|
| 224. |
XKAH-00328
|
[2] |
PLUG
|
|
| 228. |
XKAH-00045
|
[2] |
SPRING
|
|
| 279. |
XKAH-00047
|
[2] |
O-RING
|
|
| 226. |
XKAH-00043
|
[2] |
PLUG
|
|
| 227. |
XKAH-00879
|
[2] |
VALVE-CHECK
|
|
| 230. |
XKAH-00046
|
[2] |
SPRING
|
|
| 234. |
XKAH-00048
|
[2] |
O-RING
|
|
| 221. |
XKAH-00032
|
[1] |
PLUG-RO
|
|
| 238. |
XKAH-00035
|
[1] |
O-RING
|
|
| 252. |
XKAH-00327
|
[4] |
PLUG-PT
|
|
| 244. |
XKAH-00880
|
[5] |
PLUG
|
|
| 268. |
XKAH-00056
|
[2] |
BALL-STEEL
|
|
| 242. |
XKAH-00411
|
[1] |
VALVE
|
|
| 272. |
XKAH-00462
|
[1] |
SEAT-VALVE
|
|
| 276. |
XKAH-00382
|
[1] |
RING
|
|
| 275. |
XKAH-00383
|
[1] |
SPRING
|
|
| 218. |
XKAH-00881
|
[1] |
SEAT-VALVE
|
|
| 219. |
XKAH-00392
|
[1] |
VALVE
|
|
| 220. |
XKAH-00391
|
[1] |
SPRING
|
|
| 222. |
XKAH-00390
|
[1] |
RING(FOR T-TYPE)
|
|
| 233. |
XKAH-00389
|
[1] |
O-RING
|
|
| 263. |
XKAH-01039
|
[1] |
VALVE-TWO SPEED
|
|
| 264. |
XKAH-01041
|
[1] |
PLUG RO
|
|
| 265. |
XKAH-00052
|
[1] |
O-RING
|
|
| 266. |
XKAH-00384
|
[1] |
SPRING(TWO SPEED)
|
|
| 241. |
XKAH-00065
|
[2] |
PIN-PARALLEL
|
|
| 282. |
XKAH-00066
|
[9] |
BOLT-SOCKET
|
|
| 297. |
XKAH-00885
|
[1] |
ORIFICE
|
|
| N199. |
XKAH-01042
|
[1] |
NAME PLATE
|
|
| 200. |
XKAH-00116
|
[2] |
SCREW-RIVET
|
|
| K. |
XKAH-01054
|
[1] |
SEAL KIT
|
|
