神钢零件查询(SK130) - EXCAVATOR BTW LPU1001 - LPU2000 (1/98-12/98) (05-005) - STARTING AID INSTAL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
195 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N8651F1 | [1] | STARTING AID INSTAL | |
| 1. | 2418T27015 | [1] | PLATE | |
| 2. | 2436P336 | [1] | VALVE ASSY | VALVE ASSY |
| 3. | ZW26X08000 | [6] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 4. | ZS18C08025 | [1] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 5. | ZX15D02300 | [1] | TUBE | KOBTUBE |
| 6. | 2418Z1382D1 | [1] | TUBE | KOBHOSE |
| 7. | 2432Z290 | [5] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 8. | 2432Z290D3 | [5] | CLIP | KOBWire Ties -- 154mm Long Superseded by part number: PY01P01043D3 |
