现代零件查询R340LC-7(INDIA) PILOT HYD PIPING(BASE 3, TYPE I)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
259 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 5. |
31EK-11130
|
[3] |
COUPLING-SCREW
|
|
| 8. |
X500-110001
|
[5] |
CONNECTOR-ORFS
|
|
| 11. |
X520-110001
|
[4] |
ELBOW-90,ORFS
|
|
| 12. |
X520-110002
|
[1] |
ELBOW-90,ORFS
|
|
| 16. |
X520-110013
|
[1] |
ELBOW-90,ORFS
|
|
| 17. |
X820-045151
|
[1] |
ADAPTER-TEE
|
|
| 23. |
X500-110017
|
[1] |
CONNECTOR-ORFS
|
|
| 27. |
X520-110016
|
[1] |
ELBOW-90,ORFS
|
|
| 30. |
S621-014001
|
[2] |
O-RING
|
|
| 33. |
S631-011004
|
[8] |
O-RING
|
|
| 34. |
S631-014004
|
[2] |
O-RING
|
|
| 36. |
S631-024004
|
[2] |
O-RING
|
|
| 38. |
S551-050203
|
[10] |
CLAMP-BAND
|
|
| 42. |
S035-082526
|
[2] |
BOLT-W/WASHER
|
|
| 47. |
31N8-24100
|
[1] |
HOSE ASSY
|
|
| 50. |
P930-082020
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 53. |
X420-042009
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 57. |
X420-042013
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 60. |
X420-042050
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 62. |
P930-043056
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 65. |
X400-062047
|
[1] |
HOSE ASSY-SYNF,ORFS
|
|
| 67. |
X400-062078
|
[1] |
HOSE ASSY-SYNF,ORFS
|
|
| 69. |
S621-011001
|
[12] |
O-RING
|
|
| 70. |
S621-012001
|
[4] |
O-RING
|
|
| 76. |
P930-043058
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 79. |
31L7-10240
|
[1] |
CLAMP-TUBE,INS
|
|
| 80. |
S037-102026
|
[1] |
BOLT-W/WASHER
|
|
| 78. |
31Q4-40820
|
[1] |
SENSOR-PRESSURE
|
|
| 79. |
31Q4-20170
|
[1] |
TEE-TEST PORT
|
|
