凯斯零件查询(FLX3020) - FLOATER (6/06-1/12) (02-01) - WATER PUMP SYSTEM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
229 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87308650
|
[1] |
KIT, WATER PUMP REPA
|
RAC
Inc. 2 - 4
|
| . . |
87308650R
|
[1] |
REMAN-WATER PUMP
|
RAC
FLX3020 (6/06-)
|
| . . |
87308650C
|
[1] |
CORE-WATER PUMP
|
RAC
Return Number
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Pulley
|
| 3. |
238-5244
|
[1] |
O-RING,0.139" Thk x 4.234" ID, -244, Cl 5, 75 Duro
|
CAS
Superseded by part number: 455025
|
| 5. |
J942896
|
[1] |
SUPPORT
|
CAS
Fan, Includes 6 - 10
|
| 7. |
J923044
|
[1] |
RETAINER
|
CAS
Superseded by part number: J923044AM
|
| 8. |
J907769
|
[1] |
BOLT,Hex, M10 x 70mm, Cl 12.9
|
CAS
hex, special, M10 x 70 mm, class 12.9
|
| 8A. |
J910739
|
[1] |
BALL BEARING,35mm ID x 64mm OD x 37mm W
|
CAS
|
| 9. |
100-21250
|
[2] |
SNAP RING,2.50", Int, #250
|
CAS
Superseded by part number: 34039
|
| 10. |
J911924
|
[1] |
HUB
|
CAS
|
| 11. |
844-10050
|
[4] |
BOLT,Hvy Hex, M10 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 16587625
|
| 12. |
J926855
|
[1] |
PULLEY,187.23mm OD
|
CAS
|
| 15. |
87531512
|
[1] |
BELT TENSIONER
|
BN
|
| 16. |
J282433
|
[1] |
FLANGE BOLT,Hex, M10 x 1.5 x 85mm
|
CAS
|
| 17. |
87521716
|
[1] |
V-BELT,2270.00 mm L
|
BN
Fan
|
| 24. |
87351192
|
[3] |
BOLT
|
CAS
M8 x 28
|
| 25. |
J915490
|
[1] |
PLATE
|
RAC
|
| 26. |
844-10025
|
[4] |
BOLT,Hex, M10 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 9804261
|
