凯斯零件查询(FLX3020) - FLOATER (6/06-1/12) (02-12) - OIL FILTER AND COOLER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
492 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87340627
|
[1] |
FILTER HEAD
|
CAS
Superseded by part number: 87340625
|
| 2. |
J906619
|
[2] |
PLUG,1/8" - 27
|
CAS
pipe, 1/8-27 hex socket
|
| 3. |
A77722
|
[1] |
PIN,7.95mm OD x 12.83mm L
|
CAS
|
| 4. |
263136
|
[1] |
MAGNETIC PLUG,Sq. Soc, 3/4"-14 NPTF
|
NH
PLUG, MAGNETIC
|
| 5. |
J936365
|
[1] |
VALVE PRESSURE RELIE
|
CAS
Superseded by part number: 4896410
|
| 6. |
J945967
|
[1] |
PLUNGER
|
CAS
|
| 7. |
87340755
|
[1] |
SPRING
|
CAS
|
| 8. |
J931084
|
[1] |
PLUG
|
CAS
24 mm, Inc. 9
|
| 9. |
J930911
|
[1] |
O-RING,0.07" Thk x 0.8" ID
|
CAS
3/4 ID x 1/16 Superseded by part number: J930911AM
|
| 10. |
87421315
|
[8] |
FLANGE BOLT,Hex, M8 x 1.25 x 65mm, Cl 10.9
|
BRR
M8 x 65; 10.9
|
| 10. |
87409553
|
[1] |
BOLT
|
CAS
With Stud, M8
|
| 11. |
366700A1
|
[1] |
ENGINE OIL FILTER
|
L
Superseded by part number: 84485647
|
| 12. |
87447957
|
[1] |
GASKET,1.2mm Thk
|
CAS
|
| 13. |
87452245
|
[1] |
CORE-OIL COOLER
|
RAC
|
| 14. |
J918174
|
[1] |
GASKET,0.71mm Thk
|
CAS
Superseded by part number: J918174AM
|
| 15. |
J934410
|
[1] |
BY-PASS VALVE
|
CAS
Inc. 16
|
| 16. |
A77724
|
[1] |
O-RING,3.05mm Thk x 23.62mm ID
|
CAS
|
| 17. |
87314031
|
[1] |
COVER
|
RAC
Superseded by part number: 87314167AM
|
| 18. |
J929011
|
[1] |
GASKET,1.19mm Thk
|
CAS
|
| 19. |
J907860
|
[4] |
FLANGE BOLT,Hex, M8 x 25mm, Spcl
|
CAS
|
| 20. |
217-466
|
[1] |
DRAIN PLUG,Sq Soc, 1/2" - 14, NTPF
|
CAS
Superseded by part number: 86625118
|
