87356216
|
[1] |
REMAN-CRANKSHAFT
|
BRR
Remanufactured, Only For N.A. Superseded by part number: 87356215
|
| . . |
87356215R
|
[1] |
REMAN-CRANKSHAFT
|
BRR
FLX3020 FLOATER (6/06-), Reman for Reman PN 87356216
|
| . . |
87356215C
|
[1] |
CORE-CRANKSHAFT
|
BRR
Return Number
|
| 1. |
87356215
|
[1] |
CRANKSHAFT
|
BRR
With Speed Indicator Ring
|
| 2. |
J918776
|
[1] |
GEAR
|
CAS
Superseded by part number: J918776AM
|
| 3. |
J904483
|
[1] |
PIN,6.01mm OD x 8mm L
|
CAS
|
| 4. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Seal, Order A77790, REF 14
|
| 5. |
87357611
|
[1] |
DAMPER
|
RAC
|
| 5A. |
87422144
|
[1] |
PULLEY,199.42mm OD
|
CAS
|
| 6. |
J914118
|
[5] |
FLANGE BOLT,Hex, M14 x 1.5 x 60mm, Cl 12.9
|
CAS
M14 x 35
|
| 8. |
J933384
|
[1] |
REAR COVER
|
CAS
|
| 9. |
87447962
|
[1] |
GASKET,0.8mm Thk
|
CAS
|
| 10. |
J991306
|
[8] |
BOLT
|
CUR
SCREW M6 x 16; 10,9 Superseded by part number: 84994589
|
| 11. |
J945930
|
[6] |
BEARING SET
|
CAS
Main, Standard
|
| 11. |
J945931
|
[6] |
BEARING SET
|
CAS
Main, Undersize 0,25 mm
|
| 11. |
J945932
|
[6] |
BEARING SET
|
CAS
Main, Undersize 0,50 mm
|
| 11. |
J945933
|
[6] |
BEARING SET
|
CAS
Main, Undersize 0,75 mm
|
| 11. |
J945934
|
[6] |
BEARING SET
|
CAS
Main, Undersize 1,00 mm
|
| 12. |
J945929
|
[1] |
THRUST BEARING
|
CAS
Thrust, Standard Superseded by part number: J945929AM
|
| 12. |
J945922
|
[1] |
THRUST BEARING
|
CAS
Thrust, Undersize 0,25 mm
|
| 12. |
J945923
|
[1] |
THRUST BEARING
|
CAS
Thrust, Undersize 0,50 mm
|
| 12. |
J945924
|
[1] |
THRUST BEARING
|
CAS
Thrust, Undersize 0,75 mm
|
| 12. |
J945925
|
[1] |
THRUST BEARING
|
CAS
Thrust, Undersize 1,00 mm
|
| 12. |
J945926
|
[1] |
THRUST BEARING
|
CAS
Thrust, Standard, Oversize 0,25 mm
|
| 12. |
J945927
|
[1] |
THRUST BEARING
|
CAS
Thrust, Standard, Oversize 0,50 mm
|
| 12. |
J945928
|
[1] |
THRUST BEARING
|
CAS
Thrust, Undersize 0,50 mm, Oversize 0,50 mm
|
| 13. |
J918113
|
[1] |
SHIELD,74.73mm ID x 91.7mm OD x 6mm Thk
|
CAS
Order A77790, REF 14
|
| 14. |
A77790
|
[1] |
SEAL KIT
|
CAS
Crankshaft, Front, Inc. 15 - 18
|
| 19. |
A77808
|
[1] |
SERVICE KIT
|
CAS
Crankshaft, Front, Inc. 20 - 23 Superseded by part number: A77808AM
|
| 23. |
J924987
|
[1] |
SHIELD,77.14mm ID x 89.38mm OD x 6.35mm Thk
|
CAS
|
| 24. |
87339552
|
[1] |
SEAL KIT
|
CAS
Crankshaft, Rear, Inc. 24A, 25, 26 Superseded by part number: J934486
|
| 27. |
A77810
|
[1] |
SERVICE KIT
|
CAS
Crankshaft, Rear, Inc. 28, 29 Superseded by part number: A77810AM
|
| 30. |
87434865
|
[1] |
SEAL
|
CAS
Dust
|
| 34. |
87335719
|
[1] |
RING
|
CAS
Speed Indicator
|
| 35. |
87335729
|
[4] |
BOLT
|
CAS
M6 x 1 x 12
|
| 36. |
J329899
|
[1] |
DOWEL,5.01mm OD x 10mm L
|
CAS
|
