凯斯零件查询(FLX3020) - FLOATER (6/06-1/12) (03-04) - FUEL FILTER AND CONNECTIONS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
303 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
844-10020
|
[2] |
BOLT,Hvy Hex, M10 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86050286
|
| 2. |
87349484
|
[3] |
ADAPTER
|
CAS
|
| 3. |
87346600
|
[3] |
SEALING WASHER,11.71mm ID x 19.3mm OD x 1.27mm Thk
|
CAS
|
| 4. |
637-72081
|
[3] |
O-RING,1.6mm Thk x 8.1mm ID, Cl 7, 75 Duro
|
CAS
Superseded by part number: 86625087
|
| 5. |
J678923
|
[3] |
PLUG,M10 x 1
|
CAS
10 mm
|
| 6. |
87356155
|
[1] |
ADAPTER
|
BRR
Superseded by part number: 84131590
|
| 7. |
87356193
|
[1] |
FUEL FILTER
|
CAS
Superseded by part number: 84477359
|
| 8. |
87360565
|
[1] |
FUEL FILTER
|
FAR
Superseded by part number: 84477358
|
| 9. |
87349753
|
[1] |
ADAPTER
|
CAS
|
| 10. |
87349727
|
[2] |
BOLT
|
CAS
|
| 11. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
HEAD, FILTER
|
| 12. |
87356110
|
[1] |
BRACKET
|
BRR
|
| 13. |
87341273
|
[1] |
FUEL TUBE,0.63" OD
|
CAS
Fuel Supply
|
| 14. |
87341277
|
[1] |
FUEL TUBE
|
CAS
Fuel Supply
|
| . . |
326380A1
|
[1] |
ELBOW
|
CAS
(Not Shown)
|
