神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (01-007) - FUEL TANK ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
369 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N8502F2 | [1] | TANK ASSY FUEL | |
| 2. | 2446R326 | [1] | FILTER STRAINER | KOBTANK, FUEL |
| 3. | 2444R1047 | [1] | FILLER CAP | KOB |
| 4. | 2444Z3688 | [1] | COCK | KOBDRAIN |
| 5. | ZE82T08000 | [1] | PLUG | KOB1/2" PT |
| 7. | ZS31C05012 | [5] | BOLT,Phillips Drive, Pan HD, M5 x 12mm | KOBM05x0.8x12mm |
| 8. | ZW26X05000 | [5] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 9. | 2420Z1030 | [1] | KEY | KOB(SUPPLIED SEPARATELY NOT WITH CAP) Superseded by part number: YN50S01010P1 |
| 10. | ZS13C16035 | [4] | SCREW | KOBM16x2.0x35mm |
| 11. | ZW13H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 12. | 2418T17283D1 | [3] | SPACER | KOB |
| 14. | LP20PU0001P1 | [1] | TANK | KOBFUEL |
| 15. | LE52S00003F1 | [1] | LEVEL GAUGE CONTROL | KOBSENSOR |
| 16. | NSS | [1] | NOT SOLD SEPARAT | CONPACKING (SENDING UNIT PART) |
