神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (00-002) - SLEEVE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
988 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ZA93S10000 | [1] | TUBE NUT | KOBTUBE SIZE ød 10 (AMC) |
| 2. | ZA93S15000 | [1] | FERRULE | KOBTUBE SIZE ød 15 (AMC) |
| 3. | ZA93S18000 | [1] | FERRULE | KOBTUBE SIZE ød 18 (AMC) |
| 4. | ZA93S22000 | [1] | RING | KOBTUBE SIZE ød 22 (AMC) |
| 5. | ZA93S28000 | [1] | FERRULE | KOBTUBE SIZE ød 28 (AMC) |
| 6. | ZA93S35000 | [1] | FERRULE | KOBTUBE SIZE ød 35 (AMC) |
| 7. | ZF93S06000 | [1] | FERRULE | KOBTUBE SIZE ød 6 (IHARA) Superseded by part number: ZF96N06000, ZF96S06000 |
| 8. | ZF93S08000 | [1] | FERRULE | KOBTUBE SIZE ød 8 (IHARA) Superseded by part number: ZF96S08000, ZF96N08000 |
| 9. | ZF93S10000 | [1] | FERRULE | KOBTUBE SIZE ød 10 (IHARA) Superseded by part number: ZF96S10000, ZF96N10000 |
| 10. | ZF93S12000 | [1] | FERRULE | KOBTUBE SIZE ød 12 (IHARA) Superseded by part number: ZF96N12000, ZF96S12000 |
| 11. | ZF93S15000 | [1] | FERRULE | KOBTUBE SIZE ød 15 (IHARA) |
| 12. | ZF93S18000 | [1] | FERRULE | KOBTUBE SIZE ød 18 (IHARA) |
| 13. | ZF93S22000 | [1] | FERRULE | KOBTUBE SIZE ød 22 (IHARA) |
| 14. | ZF93S28000 | [1] | FERRULE | KOBTUBE SIZE ød 28 (IHARA) Superseded by part number: ZA93S28000 |
| 15. | ZF93S32000 | [1] | FERRULE | KOBTUBE SIZE ød 32 (IHARA) |
| 16. | ZF93S35000 | [1] | FERRULE | KOBTUBE SIZE ød 35 (IHARA) |
| 17. | ZF93S38000 | [1] | FERRULE | KOBTUBE SIZE ød 38 (IHARA) |
