神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (02-005[02]) - CAB ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
772 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J17019F3 | [1] | CAB | KOB |
| 1. | 2427U1551 | [1] | GLASS | KOB Superseded by part number: 2427U1175 |
| 2. | 2427R1690 | [1] | GLASS | KOB Superseded by part number: 2427R1161 |
| 3. | 2427U1176 | [1] | GLASS | KOB |
| 4. | 2427U1177 | [1] | GLASS | KOB |
| 5. | 2427U1181F1 | [1] | WAD | KOBASSY |
| 5-1. | 2427U1181S1 | [1] | FRAME | KOBSIDE |
| 5-2. | 2427U1182 | [1] | CAB GLASS ASSY | LEC |
| 5-3. | 2427U1183 | [1] | GLASS | KOB |
| 5-4. | 2427U1181S4 | [1] | GROMMET | KOBCHANNEL |
| 5-5. | 2427U1181S5 | [2] | LOCK | KOB Superseded by part number: YT51C01024F1M |
| 5-6. | 2427U1181S6 | [4] | SCREW | KOB Superseded by part number: 2420Z1229D2 |
| 5-7. | 2427U1181S7 | [1] | EXTRUSION | KOBSTRIP.WEATHER |
| 5-8. | 2427U1181S8 | [1] | GASKET | KOBGLASS-RUN |
| 5-9. | 2427U1181S9 | [2] | STOP | KOBSTOPPER. RUBBER |
| 6. | 2427U1178 | [1] | GLASS | KOB |
| 7. | 2427U1179 | [1] | GLASS | KOBGLASS |
| 8. | 24100R173F2 | [1] | COVER | KOBASSY |
| 8-1. | 2414U227 | [1] | COVER | KOBCOVER Superseded by part number: 2414U431 |
| 8-2. | 24100R168F1 | [2] | LOCK | KOBLOCK ASSY |
| 8-2A. | 2416R280 | [1] | BASE | KOB |
| 8-2B. | 2406R277 | [1] | HANDLE | KOBLOCK |
| 8-2C. | 2414R280 | [1] | COVER | KOB |
| 8-2D. | 2418R276D1 | [1] | PACKING | KOB |
| 8-2E. | 2417R77 | [1] | SPRING | KOB |
| 8-2F. | 2418R505 | [1] | RETAINER | KOB |
| 8-2G. | 2418R276D2 | [1] | PACKING | KOB |
| 8-3. | NSS | [8] | NOT SOLD SEPARAT | CONSCREW. TAPPING |
| 8-4. | 24100R173S6 | [2] | TAPE | KOBMAGIC TAPE |
| 8-8. | 2416U238 | [2] | BRACKET | KOBBRACKET |
| 8-9. | NSS | [4] | NOT SOLD SEPARAT | CONNUT |
| 8-10. | NSS | [4] | NOT SOLD SEPARAT | CONLOCK WASHER |
| 8-11. | NSS | [4] | NOT SOLD SEPARAT | CONWASHER |
| 8-12. | 2420R588 | [2] | HINGE | KOB |
| 8-13. | NSS | [4] | NOT SOLD SEPARAT | CONNUT |
| 8-14. | NSS | [4] | NOT SOLD SEPARAT | CONLOCK WASHER |
| 8-15. | NSS | [4] | NOT SOLD SEPARAT | CONWASHER |
| 8-16. | 2427R1160 | [1] | SUN VISOR | KOB |
| 9. | 2427U1180 | [1] | GLASS | KOB |
| 10. | 2427U1354F1 | [1] | WINDOW | KOBSASH ASSY |
| 10-1. | 2427U1354S1 | [1] | FRAME | KOB |
| 10-2. | 2427U1356 | [1] | GLASS | KOB |
| 10-3. | 2427U1355 | [1] | GLASS | KOB |
| 10-4. | 2427U1184S4 | [1] | GROMMET | KOBCHANNEL |
| 10-5. | 2427U1181S5 | [2] | LOCK | KOB Superseded by part number: YT51C01024F1M |
| 10-6. | 2427U1181S6 | [4] | SCREW | KOB Superseded by part number: 2420Z1229D2 |
| 10-7. | 2427U1184S7 | [1] | EXTRUSION | KOBSTRIP. WEATHER |
| 10-8. | 2427U1184S8 | [1] | GLASS | KOBRUN Superseded by part number: 77255037, 2427U1354S8 |
| 10-9. | 2427U1181S9 | [2] | STOP | KOBSTOPPER. RUBBER |
| 14. | 2427R1152 | [1] | RUBBER SLEEVE | KOB |
| 15. | 2427R1167 | [1] | RUBBER SLEEVE | KOB |
| 16. | 2427R1168 | [1] | RUBBER SLEEVE | KOB |
| 17. | 2427R1153 | [1] | RUBBER SLEEVE | KOB |
| 18. | 2427U1500 | [1] | RUBBER SLEEVE | KOB |
| 19. | 2427U1193 | [1] | RUBBER SLEEVE | KOB |
| 20. | 2418R507 | [1] | DOOR SEAL | KOBFINISHER |
| 21. | 2418R507D2 | [1] | DOOR SEAL | KOBFINISHER Superseded by part number: 2418R507 |
| 23. | 24100U1018S28 | [8] | SET SCREW | KOBBOLT. SET |
| 26. | 2429P1228 | [1] | HANDRAIL | KOB |
| 30. | 2406R234D2 | [1] | HANDLE | KOB |
| 31. | 24100J11965S31 | [2] | SCREW | KOB |
| 32. | 2427U1187 | [2] | RUBBER SLEEVE | KOB |
| 33. | 24100J11965S33 | [2] | SET SCREW | KOBBOLT. SET |
| 34. | 24100J6512S23 | [1] | PLATE | KOBPLATE ASSY |
| 35. | 24100J6107S34 | [4] | SCREW | KOBSETSCREW Superseded by part number: ZM41C06012 |
| 36. | 24100U1194F2 | [1] | LOCK | KOBDOOR |
| 37. | 24100J11965S37 | [3] | SCREW | KOBSETSCREW |
| 38. | 2406U198D4 | [1] | HANDLE | KOBASSY |
| 39. | 24100J11965S39 | [2] | FLANGE NUT | KOBFLANGE |
| 40. | 2421U75 | [1] | LH DOOR LOCK | KOB |
| 41. | 2432R239 | [1] | CLIP | KOB |
| 42. | 2406U194D2 | [1] | HANDLE | KOBASSY |
| 44. | 24100J14396S44 | [1] | SCREW | KOB |
| 45. | 2408U113 | [1] | HOOK | KOB |
| 46. | 24100J11965S46 | [2] | SET SCREW | KOB |
| 47. | 24100U1435 | [1] | WINDOW | KOBASSY |
| 48. | 2416R529 | [1] | PAD | KOB |
| 50. | 2416U293 | [1] | PAD | KOB |
| 51. | 2416U243 | [1] | PAD | KOB |
| 52. | 24100J6512S41 | [11] | CLIP | KOB |
| 53. | 2432R236 | [9] | CLIP | KOB |
| 54. | 2479R2074 | [1] | HARNESS | KOB |
| 56. | 24100J14396S56 | [1] | HARNESS | KOB |
| 57. | 2479U1298 | [1] | HARNESS | KOB |
| 59. | 2479R704 | [1] | WIPER | KOBMOTOR. WIPER Superseded by part number: YT53C00011F1 |
| 60. | 2488U75 | [1] | WIPER ARM | KOBARM. WIPER Superseded by part number: GB53C00001P1 |
| 61. | 2488U76 | [1] | WIPER BLADE | KOB Superseded by part number: EN53C00003P1 |
| 62. | 24100U1235 | [1] | WASHER | KOBWASHER ASSY |
| 63. | 2456Z322F1 | [1] | LIGHT,24V, 5W | KOBLAMP. ROOM |
| 63-1. | 2456Z322S1 | [1] | LENS | KOBLENS |
| 63-2. | 2456Z322S2 | [1] | CASE | KOBCASE |
| 63-3. | 2456Z322S3 | [1] | BULB | KOB Superseded by part number: YT80S00004P1 |
| 64. | 24100J6512S55 | [2] | SCREW | KOBSCREW Superseded by part number: ZS18C05014 |
| 65. | 2475U74 | [1] | ANTENNA | KOB Superseded by part number: YT54S00018F1 |
| 66. | ZS18C10030 | [3] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 67. | 24100J11965S67 | [1] | RUBBER SEAL | KOB |
| 68. | 2427U1400 | [1] | EXTRUSION | KOB |
| 69. | 24100J6512S103 | [1] | ASH TRAY | KOB |
| 70. | 24100J6512S104 | [2] | SCREW | KOB |
| 71. | 2408U111 | [1] | HOOK | KOB |
| 72. | 24100J6107S14 | [2] | NUT | KOB |
| 73. | 24100J6107S15 | [2] | WASHER | KOB |
| 75. | 2420R578 | [1] | GROMMET | KOB Superseded by part number: YT51C01039P1 |
| 76. | 2427U1191 | [1] | HANDLE | KOBCATCH |
| 77. | 24100J6284S75 | [4] | SCREW | KOBBOLT. SET |
| 78. | 2420U194D1 | [2] | NUT | KOB |
| 79. | 2418R506D3 | [2] | RUBBER SEAL | KOB |
| 80. | 2418R277 | [11] | SPACER | KOB |
| 81. | 2418R604 | [3] | SPACER | KOB |
| 84. | 24100R271 | [1] | WIRE | KOBWIRE ASSY |
| 86. | 2416R279 | [2] | HOLDER | KOBHOLDER ASSY |
| 87. | 24100J11965S87 | [4] | SET SCREW | KOBBOLT. SET |
| 88. | 2418U415 | [1] | RUBBER SEAL | KOB |
| 89. | 2418U415D2 | [1] | RUBBER SEAL | KOB |
| 90. | 2416R462 | [2] | HOLDER | KOB |
| 91. | 24100J11965S167 | [4] | SET SCREW | KOB |
| 93. | 2427R1139 | [2] | HANDLE | KOBCATCH |
| 94. | 24100J11965S94 | [4] | SCREW | KOB |
| 95. | 2417U169D2 | [2] | SPRING | KOB Superseded by part number: YN02C01196P1 |
| 96. | 24100J14396S96 | [4] | RING | KOB |
| 97. | 2416Z464 | [2] | STOP | KOBSTOPPER |
| 98. | ZN18F10008 | [2] | NUT | KOBM10x1.25mm |
| 99. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 100. | 2416U310 | [1] | HOLDER | KOBHOLDER |
| 101. | 24100J6512S159 | [1] | GLASS | KOB |
| 102. | 24100J11965S102 | [4] | SET SCREW | KOBBOLT. SET |
| 103. | 24100J11965S103 | [2] | CHANNEL | KOB |
| 106. | 24100J6512S143 | [1] | SWITCH | KOBDOOR |
| 107. | 24100J11965S168 | [2] | SELF-TAP SCREW | KOB |
| 108. | 24100J11965S108 | [2] | GASKET | KOBGLASS-RUN |
| 109. | 24100J6512S115 | [2] | SEAL | KOB Superseded by part number: 24100J6436S27 |
| 110. | 24100J6512S70 | [1] | RUBBER SEAL | KOB |
| 112. | 2418R548D2 | [1] | RUBBER SEAL | KOB |
| 113. | 2427R1133 | [2] | RUBBER SLEEVE | KOB |
| 114. | 2427U1188 | [2] | STOP | KOB |
| 115. | 24100J11965S115 | [2] | SET SCREW | KOBSETSCREW |
| 116. | 2473U1 | [1] | BRUSH | KOB |
| 117. | 24100J10783S107 | [5] | RIVET | KOB |
| 118. | 2473U2 | [1] | BRUSH | KOB |
| 119. | 2414U207 | [1] | COVER | KOB |
| 120. | 24100J14396S120 | [6] | SCREW | KOBTAPPING |
| 123. | 2408U110D1 | [1] | GUARD | KOBGUARD,PIPE |
| 124. | 2408U110D2 | [1] | GUARD | KOBPIPE |
| 125. | 2408R116 | [1] | GUARD | KOBPIPE |
| 126. | 24100J11965S126 | [6] | SET SCREW | KOBSETSCREW |
| 127. | 2427U3044 | [1] | RUBBER SLEEVE | KOBGARNISH |
| 128. | 24100J6512S122 | [1] | HOOK | KOBHANGER ASSY |
| 129. | 2420R576 | [1] | SHIELD | KOBGROMMET |
| 132. | ZS31C03010 | [2] | SCREW,Phillips Drive, Pan HD, M3 x 10mm | KOBM03x0.5x10mm |
| 133. | ZN16C03003 | [2] | NUT | KOB(M3) |
| 134. | 24100J11965S134 | [3] | FASTENER | KOB |
| 135. | 2413R161 | [4] | ROLLER THRUST PLATE | KOB |
| 136. | 24100J11965S136 | [8] | WASHER | KOB |
| 137. | 24100J11965S137 | [4] | WASHER | KOB |
| 138. | 24100J11965S138 | [1] | GROMMET | KOB |
| 139. | 2420R429D2 | [5] | GROMMET | KOB |
| 140. | 2420U191D3 | [1] | GROMMET | KOB |
| 141. | 2414R281 | [1] | COVER | KOB |
| 142. | 24100J11965S142 | [1] | BAND | KOB |
| 143. | 2418U414 | [1] | RUBBER SEAL | KOB |
| 145. | 2418R512 | [1] | SPACER | KOB |
| 146. | 2418R514 | [1] | RUBBER SEAL | KOB |
| 147. | 2414R282S1 | [1] | COVER | KOB Superseded by part number: 2414R282D1 |
| 149. | 24100J11965S149 | [3] | LOCK WASHER | KOB |
| 150. | 24100J11965S150 | [3] | WASHER | KOB |
| 158. | 2418R506D4 | [1] | RUBBER SEAL | KOB |
| 164. | 2405R68 | [2] | BUSHING | KOB |
| 167. | 2414R445 | [1] | COVER | MOD |
| 168. | 2406R498 | [1] | LEVER | KOB |
| 169. | 2420R606D3 | [1] | RIGID TUBE | KOBPIPE |
| 170. | 2429R237 | [1] | GUIDE | KOB |
| 171. | 2429R238 | [1] | GUIDE | KOB |
| 175. | 24100J14396S175 | [1] | SPRING | KOB |
| 176. | 2414R447 | [1] | COVER | KOB |
| 178. | 24100J14396S178 | [2] | SCREW | KOBSCREW |
| 182. | 2405R306 | [1] | BUSHING | KOB |
| 183. | 24100J14396S183 | [2] | CLAMP | KOB |
| 188. | 24100J14396S188 | [2] | SCREW | KOB |
| 189. | 24100J14396S189 | [2] | WASHER | KOB |
| 315. | 2427U1479D15 | [1] | CAB | |
| 315-15. | 2427U1526D2 | [1] | CABIN DOOR | KOBDOOR ASSY |
| 315-15C. | 2420Z1253 | [2] | HINGE | KOB |
| 315-15D. | ZW16X10000 | [6] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 315-15E. | ZW26X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 315-15F. | ZS18C10025 | [6] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 315-18. | ZW16X10000 | [6] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 315-20. | ZN17C10008 | [6] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| . . | 24100R169F1 | [1] | CABIN DOOR | KOBDOOR ASSY |
