凯斯零件查询(FLX3300B) - FLOATER - 1999 (12/99-9/02) (02-002[02]) - ENGINE GROUP (FLX3330B CAT 3208ATAAC) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
791 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
413-1216
|
[2] |
BOLT,Hex, 3/4" - 10 x 1", Gr 5
|
CAS
|
| 2. |
BN2290173
|
[1] |
FITTING
|
BN
2103-4-6
|
| 3. |
BN2290278
|
[1] |
BUSHING
|
BN
0102-6-2
|
| 4. |
BN2290291
|
[1] |
BUSHING
|
BN
0102-4-2
|
| 5. |
BN2290298
|
[2] |
BUSHING
|
BN
0102-12-6
|
| 6. |
BN2292195
|
[1] |
Cat 3208T 330Hp
|
|
| 7. |
BN2292249
|
[2] |
HYDRAULIC VALVE
|
BN
Everhot
|
| 8. |
BN51674
|
[1] |
HOSE CLAMP
|
BN
Adjustable #40
|
| 9. |
BN2293521
|
[1] |
FITTING
|
BN
2102-6-6
|
| 10. |
BN2293687
|
[1] |
FITTING
|
BN
744240
|
| 11. |
BN2394965
|
[1] |
TEMPERATURE SENDER
|
BN
|
| 12. |
BN2396287
|
[2] |
V-BELT
|
BN
Alternator, Air Compressor
|
| 13. |
BN312105
|
[1] |
FAN
|
BN
|
| . . |
BN2396838
|
[1] |
HEATER
|
BN
Water (3208) 120V
|
| 14. |
BN2399638
|
[1] |
FITTING
|
BN
4MP-4FP
|
| 15. |
BN2400295
|
[2] |
BELT
|
BN
|
| 16. |
BN2401945
|
[1] |
SENDER UNIT
|
BN
Tach 71255
|
| 17. |
BN2404997
|
[1] |
PRESSURE SWITCH
|
BN
N.O.
|
| 18. |
NSS
|
[6] |
NOT SOLD SEPARAT
|
CON
3/8, FW, G8
|
| 19. |
BN303492
|
[1] |
SPACER
|
BN
330, Cat
|
| 20. |
BN305703
|
[1] |
Throttle
|
|
| 24. |
BN319231
|
[1] |
A/C
|
|
| 25. |
BN50274
|
[6] |
BOLT
|
BN
3/8-16 X 2.75 (Cat)
|
| 26. |
BN2292194-008
|
[1] |
Pulley Adjuster ALT.
|
|
| 27. |
BN2292194-010
|
[1] |
PIPE CLAMP
|
BN
Turbo 3208 9N2039
|
| 30. |
BN319214
|
[1] |
PULLEY
|
BN
2A6.63, Cat
|
| 31. |
BN319223
|
[1] |
PLATE
|
BN
Orifice
|
| 32. |
BN319222
|
[1] |
GASKET
|
BN
Water Fill 3208
|
