| . . | 24100J17490F1 | [1] | LABEL | KOB Superseded by part number: 2432N2978, YN20T01015P2, 2432T6111, YN57V00002S007, YN20T01221P1, YN20T01416P1, YN20T01407P1, 2432P2689, 2432P3055, 2432Z928, 2432P3736, 2432P3393, YN20T01006P1, 2432P3308, 2432P3769, 2432T6109, 2432T6110, 2432P3737, 2432P3770, 2432P3771, 2432T5613, 2432T6108, 2432T6129, 2432T6457, 2432T6573, 2420P623D7, ZL11N00404, YN20T01213P1, 2432N2977, YN20T01097P1, YN20T01017P1, YN20T01048P1, YN20T01016P1, YN20T01013P1, YN20T01012P1, YN20T01003P2, YN20T01001P1, 2427Z1432, 2432P3617D1, 2432P3390, 2432N2980, 2432P3383, ZL11N05204, 2432P3379, 2432N3174, 2432N3173, 2432N3172, 2432N3145, 2432N3144, 2432N2979, ZL11N00504 |
| 1. | 2432P3300 | [1] | TYPE PLATE | KOBNAME |
| 2. | 2432P3395 | [1] | LABEL | KOB |
| 3. | 2432P3394 | [1] | LABEL | KOB |
| 4. | 2432P3393 | [2] | LABEL | KOB |
| 5. | 2432N2977 | [1] | LABEL | KOB |
| 6. | 2432N2978 | [1] | LABEL | KOB |
| 7. | 2432P3396 | [1] | LABEL | KOBLABEL |
| 8. | 2432P3397 | [1] | LABEL | KOB |
| 9. | 2432T6126 | [2] | TYPE PLATE | KOBNAME |
| 10. | 2432P3390 | [2] | TYPE PLATE | KOBNAME |
| 11. | 2432T5613 | [1] | IDENTITY PLATE | KOBName plate, Kobelco - Model, Serial number, Manufacture year |
| 12. | 4020Z64 | [4] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 13. | YN20T01006P1 | [3] | LABEL | KOBDecal, Danger, Contact with electrical power lines will result in … |
| 14. | 2422T590 | [1] | REWORK, FRAME 4 - \u00d85.1 holes added | REWORK, FRAME 4 - Ø5.1 holes added |
| 15. | 2432P2689 | [1] | LABEL | KOBDecal, Greasing Swing Bearing … |
| 16. | YN20T01003P1 | [2] | LABEL | KOBDecal, Danger, Keep clear of swing area. Superseded by part number: YN20T01003P2 |
| 17. | 2427Z1432 | [9] | SHEET | KOBAnti-Slip (300x110mm) |
| 18. | 2432N2980 | [1] | LABEL | KOB |
| 19. | 2432T2283 | [1] | LABEL | KOBDecal, Fuel location |
| 20. | YN20T01002P1 | [1] | LABEL | KOB Superseded by part number: YN20T01405P1 |
| 21. | 2432P3392 | [2] | TYPE PLATE | KOBNAME |
| 22. | 2446U260S9 | [1] | PLATE | KOBDecal, Caution, Air Breather |
| 23. | 2432P3308 | [1] | LABEL | KOBDecal, Yellow triangle (615x626mm) |
| 24. | 2432T6110 | [1] | LABEL | KOBDecal, Warning, Extreme high pressure in truck adjustment cylinder … |
| 25. | YN20T01097P1 | [1] | LABEL | KOBDecal, Filled with antifreeze This machine is filled with … |
| 26. | YN20T01016P1 | [1] | WARNING DECAL | KOBDecal, Warning, Read and understand operator manual before … |
| 27. | 2432T6109 | [1] | LABEL | KOBDecal, Warning, Do not install any object on the handrail. This can cause … |
| 28. | 2432T6108 | [1] | LABEL | KOBDecal, Warning, Pull out the connector when lifting the front widow. Lock … |
| 29. | 2432T6129 | [1] | LABEL | KOBDecal, Caution, Do not attempt normal machine operations when lamp … |
| 30. | YN20T01048P1 | [1] | LABEL | KOBDecal, Warning, Automatic two speed travel system changes travel speed … |
| 31. | LE20T01019P1 | [1] | LABEL | KOBDecal, Caution, Falling front window can cause injury. Always lock securely… Superseded by part number: YN20T01416P1 |
| 32. | 2432N2979 | [1] | LABEL | KOB |
| 33. | 2432P3380 | [1] | LABEL | KOBDecal, Caution, Bucket can contact and damage cab when mahine … Superseded by part number: YN20T01013P1 |
| 34. | 2432T5301 | [1] | LABEL | KOBDecal, OK Kobelco logo Superseded by part number: YN20T01407P1 |
| 35. | YN20T01012P1 | [1] | CAUTION DECAL | KOBDecal, Caution, Rotating engine fan, hot engine parts and drive belt can cause … |
| 36. | YN20T01009P1 | [1] | LABEL | KOBDecal, Warning, Rotating parts can cause personal injury… Superseded by part number: ZL11N05204 |
| 37. | YN20T01010P1 | [1] | LABEL | KOBDecal, Warning, Steam of hot coolant can cause injury or blindness… Superseded by part number: ZL11N00404 |
| 38. | YN20T01001P1 | [1] | LABEL | KOBDecal, Warning, Prevent Batter Explosion … |
| 39. | YN20T01017P1 | [1] | LABEL | KOBDecal, Warning, Avoid Acid Burns… |
| 40. | YN20T01015P1 | [1] | LABEL | KOBDecal, Warning, Improper booster cable connections can cause an explosion … Superseded by part number: YN20T01015P2 |
| 41. | 2432P3383 | [1] | LABEL | KOBDecal, Warning, Hydraulic oil can be hot after machine operation. Allow… |
| 42. | 2432P3379 | [1] | LABEL | KOBDecal, Notice, Lack of Hydraulic Oil will cause damage to Main Hydraulic pump… |
| 43. | LE20T01027P1 | [1] | LABEL | KOB |
| 52. | 2432T6111 | [1] | LABEL | KOBDecal, Warning, When servicing or repairing machine. Keep surface free of oil… |
