神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (11-003) - TOOL KIT ASSY (24100P3369F2) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
384 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P3369F2 | [1] | TOOL ASSY | |
| 22. | B16T0442D1 | [5] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| 23. | B16T0442D2 | [3] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 24. | B16T0442D5 | [1] | SHIM,130mm OD x 72mm ID x 2.3mm Thk | KOBID 72 x OD 130 x Th 2.3mm |
| 25. | B16T0442D19 | [1] | SHIM,62mm ID x 100mm OD x 1.6mm Thk | KOBID 62 x OD 100 x Th 1.6mm |
| 26. | B16T0442D20 | [1] | SHIM,100mm OD x 62mm ID x 2.3mm Thk | KOBID 62 x OD 100 x Th 2.3mm |
| 27. | B16T0442D27 | [1] | SHIM,62mm ID x 100mm OD x 1.2mm Thk | KOBID 62 x OD 100 x Th 1.2mm |
| 28. | B16T0442D29 | [3] | SHIM,130mm OD x 72mm ID x 2.0mm Thk | KOBID 72 x OD 130 x Th 2.0mm |
| 29. | B16T0442D30 | [1] | SHIM,100mm OD x 62mm ID x 2.0mm Thk | KOBID 62 x OD 100 x Th 2.0mm |
| 30. | 2418T4037D1 | [1] | SHIM,67mm ID x 110mm OD x 2.3mm thk | KOBID 67x OD 110 x Th 2.3mm |
| 31. | 2418T4037D2 | [2] | SHIM,67mm ID x 110mm OD x 1.2mm thk | KOBID 67x OD 110 x Th 1.2mm |
| 40. | 2421R380 | [1] | GREASE GUN | KOB |
| 41. | 2421Z499 | [1] | GREASE | |
