凯斯零件查询(FLX3300B) - FLOATER - 1999 (12/99-9/02) (02-053) - RADIATOR COMPONENTS (FLX3300B CAT ENGINE & FLX3330B) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
901 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
9617020
|
[1] |
PLUG,1/4" - 18 x 0.48"
|
NH
|
| 2. |
BN2290646
|
[1] |
FITTING
|
BN
744440
|
| 3. |
BN2390873
|
[1] |
HOSE,0.31" ID
|
BN
Fuel, 815-25R
|
| 4. |
BN307183
|
[1] |
RADIATOR
|
TYR
30 X 36 Core
|
| 5. |
BN314898
|
[1] |
HOSE,0.31" ID x 50.00"
|
BN
|
| 6. |
BN315211
|
[1] |
RADIATOR HOSE,2.00" ID, 2.25" ID x 11.28", SAE 20R4 Class D1 per SAE J20
|
TYR
Lower Radiator
|
| 7. |
BN315216
|
[1] |
RADIATOR HOSE,2.00" ID, 2.25" ID x 24.32", SAE 20R4 Class D1 per SAE J20
|
TYR
Upper Radiator
|
| 8. |
BN315219
|
[1] |
HOSE,1.00" ID x 24.37", SAE J20, SAE 20R4 Class D1
|
TYR
Engine Fill
|
| 10. |
BN75978
|
[2] |
HOSE CLAMP
|
BN
SS, No. 12 adj., HS, .56-1.25 Superseded by part number: BN310446
|
| 11. |
BN76020
|
[4] |
HOSE CLAMP
|
BN
1 & 1/2 - 2 Hose SS
|
| 12. |
BN76094
|
[3] |
HOSE CLAMP
|
BN
SS #M4 Superseded by part number: 87485000
|
| 13. |
43235
|
[6] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd
|
BHB
|
| 14. |
BN300497
|
[8] |
WASHER,M8, 10.9
|
BN
Superseded by part number: 896-15008
|
| 15. |
86624005
|
[2] |
CLAMP,19mm, Coat, 10.3mm Bolt Hole, P Type
|
FOR
|
| 16. |
BN318459
|
[1] |
HOSE,0.31" ID x 38.00"
|
BN
|
| 17. |
1547924C1
|
[1] |
CAP
|
IH
coolant recovery bottle Superseded by part number: 440729A1
|
| 18. |
87481454
|
[1] |
BOTTLE
|
FAR
Tank, Coolant Recovery, 5 qt
|
| 19. |
BN318614
|
[1] |
BASE PLATE
|
BN
Recovery Bottle
|
| 20. |
86528579
|
[2] |
NUT,M8 x 1.25
|
WIN
|
| 21. |
A170241
|
[1] |
RADIATOR CAP
|
CAS
15 psi Superseded by part number: 83957211
|
