| . . | 24100J17544F1 | [1] | HYD LINES, UPP (EXTRA & BREAKER) | |
| 2. | 2436U1310F1 | [1] | VALVE | KOBVALVE ASSY |
| 3. | 2446U233F1 | [1] | FILTER ASSY | KOBFILTER ASSY, INLINE |
| 3-1. | 2446U232S1 | [1] | COVER | KOB |
| 3-2. | 2446U233S2 | [1] | ELEMENT | KOBASSY |
| 3-3. | 2446U232S3 | [1] | CASE | KOB |
| 3-4. | 2446U233S4 | [1] | PLUG | |
| 3-5. | 2446U233S5 | [1] | VALVE | |
| 3-6. | 2446U233S6 | [1] | SPRING | |
| 3-7. | 2446U233S7 | [1] | PLUG | KOB |
| 3-8. | ZD12P02800 | [1] | O-RING | KOBID 27.70 ± 0.27 x OD 34mm |
| 3-9. | ZD12G11500 | [1] | O-RING,114.40mm ID x 120.60mm OD x 3.10mm | KOBID 114.40 ± 0.94 x OD 120mm |
| 3-10. | ZD11P05000 | [1] | O-RING | KOB(P50 1A) |
| 3-11. | ZD12G03000 | [1] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 3-12. | 2446U233S12 | [1] | SCREW | KOB |
| 3-13. | ZD12P01200 | [1] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 4. | 2418P24511 | [1] | RIGID TUBE | KOB |
| 5. | 2420T2948D13 | [2] | U-BOLT | KOB |
| 6. | ZW13H08000 | [4] | WASHER | KOB(M8) |
| 8. | ZA23F22012 | [1] | HYD CONNECTOR | KOB3/4"PF - M30x1.50 x 46mm Long |
| 9. | ZA23B22028 | [1] | CONTROL | KOB |
| 10. | 2444Z2348 | [1] | HYD CONNECTOR | KOB |
| 11. | ZA33F28016 | [5] | ELBOW | KOB |
| 12. | ZD12P03800 | [2] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 13. | ZD12P02900 | [5] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 14. | ZD12P02400 | [4] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 15. | 2416T13250 | [1] | U-BRACKET | KOB |
| 16. | ZW22X12000 | [10] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 17. | ZW22X10000 | [15] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 18. | 2416P16415 | [1] | SUPPORT | |
| 19. | 2416P16416 | [1] | SUPPORT | |
| 20. | ZC26X22011 | [3] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 21. | ZN13C12010 | [3] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 22. | ZS13C10050 | [3] | SCREW | KOBM10x1.50x50mm Superseded by part number: ZS18C10050 |
| 23. | ZS18C12110 | [2] | SCREW,Hex, M12 x 110mm | KOBM12x1.75x110mm |
| 24. | ZS13C12030 | [4] | CAPSCREW | KOBSCREW M12x1.75x30mm Superseded by part number: ZS18C12030 |
| 26. | 2436U1303F1 | [1] | PILOT VALVE | KOBDIVIDER, FLOW |
| 27. | 2436U1213F2 | [1] | CONTROL VALVE | KOB |
| 29. | ZE13X12000 | [4] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| 30. | YW30HU1003P1 | [1] | TUBE | KOB |
| 31. | YW30HU1002P1 | [1] | TUBE | KOB |
| 32. | 2444Z2287D6 | [2] | FLEXIBLE HOSE | KOB |
| 34. | HH25R16016G1 | [2] | HYD CONNECTOR | KOB |
| 35. | ZA33F15006 | [1] | ELBOW | KOB |
| 36. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 37. | YW30HU1005P1 | [1] | TUBE | KOB |
| 38. | YW30HU1004P1 | [1] | TUBE | KOB |
| 39. | YW30HU1001D5 | [2] | HOSE | KOB |
| 40. | 2444Z3993 | [1] | HOSE | KOB |
| 41. | 2444T2535 | [1] | HYD CONNECTOR | KOB |
| 42. | ZH42X12016 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 1", O-Ring | KOB |
| 43. | ZX22M12045 | [1] | HOSE,19.05mm ID x 450mm L | KOB450mm Long (17-23/32 in) |
| 44. | 2418T16788 | [1] | TUBE | KOB |
| 45. | 2418P25301 | [1] | TUBE | TUBE |
| 47. | 2444Z2236 | [2] | HYD CONNECTOR | KOB |
| 48. | 2418T22215 | [1] | PLATE | |
| 49. | ZC26X15009 | [3] | CLAMP | KOB |
| 50. | ZS13C08045 | [3] | SCREW | KOBM08x1.25x45mm Superseded by part number: ZS18C08045 |
| 51. | ZW22X08000 | [3] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 52. | ZN13C08007 | [9] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 54. | ZS13C10090 | [4] | SCREW | KOBM10x1.50x90mm Superseded by part number: ZS18C10090 |
| 55. | ZN13C10008 | [5] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 56. | ZS13C12045 | [3] | SCREW | KOBM12x1.75x45mm Superseded by part number: ZS18C12045 |
| 58. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 59. | ZS13C10035 | [8] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 60. | ZC26X28014 | [1] | CLAMP | KOBSingle Line -- 75x37x38mm (Ø28mm) |
| 61. | ZS13C12065 | [1] | SCREW | KOB(M12X65) Superseded by part number: ZS18C12065 |
| 63. | ZT22A03000 | [1] | WRENCH | KOBKEY, LOCK SCREW |
| 64. | 2432P1083 | [1] | LABEL | KOB |
| 65. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 68. | 2418P28264 | [1] | TUBE | KOB |
| 69. | 2418P29512 | [1] | TUBE | TUBE |
| 70. | 2418P28263 | [1] | TUBE | TUBE |
| 71. | 2418T24796 | [1] | TUBE | KOB |
| 72. | 2444Z3607 | [1] | ELBOW | KOB |
| 73. | 2418T24860 | [1] | PLATE | |
| 74. | ZW13H10000 | [1] | WASHER | KOBID 11 x OD 24 x Th 3.2mm Superseded by part number: ZW16H10000 |
| 75. | ZW13H12000 | [1] | WASHER | KOB(M12) |
| 76. | 2414T4850F4 | [1] | COVER ASSY | |
| 76-2. | 2427Z1344 | [1] | FOAM INSULATION | KOB |
| 76-3. | 2416Z263D2 | [1] | FOAM INSULATION | KOBSHEET, RUBBER |
| 76-7. | 2414P9899 | [1] | COVER | COVER |
| 77. | 2432Z290D5 | [1] | CLIP | KOBWire Ties -- 365mm Long Superseded by part number: PY01P01043D8 |
