| . . | 24100J17263F3 | [1] | POWER PLANT ASSY (ENGINE INSTALLATION) | |
| 1. | 24100N8520F1 | [1] | POWER TAKE-OFF ASSY, REF: 05-004 | |
| 2. | YW05PU0002F1 | [1] | RADIATOR | KOB |
| 3. | 2416T29617 | [1] | STAY | STAY |
| 4. | 2416T29616 | [1] | STAY | STAY |
| 5. | 2444R2698 | [1] | FLEXIBLE HOSE | KOB |
| 6. | 2444R2699 | [1] | FLEXIBLE HOSE | KOB |
| 7. | 2444R2700 | [1] | FLEXIBLE HOSE | KOB |
| 8. | YN21PU1002P1 | [2] | HYD CONNECTOR | KOB Superseded by part number: VW3908585 |
| 9. | YW12PU0002P1 | [1] | MUFFLER | KOB |
| 10. | 2420Z795D4 | [1] | HOSE | KOB Superseded by part number: HX11Y07100DX |
| 11. | 2416J2283 | [1] | BRACKET | KOB |
| 12. | ZC16X01400 | [2] | CLIP | KOBClamp, Hose -- Min 10 x Max 17mm |
| 13. | 2420T8633 | [2] | U-BOLT | KOB |
| 14. | 2416N7199 | [1] | U-BRACKET | KOB Superseded by part number: 2416N7973, 77252176 |
| 15. | 2416N7131 | [1] | U-BRACKET | KOB |
| 16. | 2416N7132 | [1] | BRACKET | KOB |
| 17. | 2416P20606 | [1] | U-BRACKET | KOB |
| 18. | 2416P20605 | [1] | BRACKET | KOB |
| 19. | 2427U203F1 | [1] | CONTAINER | KOBRADIATOR, SUB-TANK |
| 19-1. | 2427U203S1 | [1] | TANK | |
| 19-2. | 2427U203S2 | [1] | HYD CONNECTOR | KOBCONDUCTOR |
| 19-3. | 2427U203S3 | [1] | LABEL | KOBPLATE, CAUTION |
| 20. | 2416T23254 | [1] | BRACKET | KOB |
| 20-2. | 2416R259D1 | [1] | CUSHION | KOB |
| 21. | NSS | [1] | NOT SOLD SEPARAT | CONHOSE (RADIATOR PART) |
| 22. | 2418R590D1 | [1] | FLEXIBLE HOSE | HIT |
| 24. | 2444R2693 | [1] | HOSE | KOB |
| 25. | 2420P3030 | [1] | PIPE | PIPE |
| 26. | YR52S00001P1 | [1] | SENDER UNIT | KOBSENDING UNIT, THERMO |
| 27. | 2444R2669D3 | [1] | FLEXIBLE HOSE | KOB |
| 28. | 2414P9773 | [1] | U-BRACKET | KOBCOVER Superseded by part number: 2414P10932 |
| 29. | ZC16X11000 | [2] | CLIP | KOBClamp, Hose -- Min 100 x Max 121mm |
| 30. | ZC16X08700 | [2] | CLIP | KOBClamp, Hose -- Min 77 x Max 96mm |
| 31. | YN21PU1001P1 | [1] | FILTER ASSY | KOB Superseded by part number: YN02PU1004F1 |
| 32. | 2414P9763 | [1] | COVER | KOB |
| 33. | 2444R2492D150 | [1] | HOSE | KOB1500mm Long (59-3/64 in) |
| 34. | HX11F04185DX | [1] | FLEXIBLE HOSE | KOB |
| 35. | LE11P01015F1 | [1] | INDICATOR | KOBAir Filter Restriction Gauge |
| 35-1. | LE11P01015S001 | [1] | INDICATOR, TURN SIGN | KOB Superseded by part number: LV11P01017F1 |
| 35-2. | 2450R163S2 | [1] | LUBE NIPPLE | KOB |
| 36. | ZS13C18090 | [4] | SCREW | KOBM18x2.0x90mm |
| 37. | ZS13C12035 | [8] | CAPSCREW | KOBSCREW M12x1.75x35mm Superseded by part number: ZS18C12035 |
| 38. | ZC16X01200 | [3] | CLIP,8mm - 15mm | KOBClamp, Hose -- Min 08 x Max 15mm |
| 39. | ZC16X05800 | [2] | CLIP | KOBClamp, Hose -- Min 50 x Max 66mm |
| 40. | ZC16X07000 | [1] | CLIP | KOBClamp, Hose -- Min 60 x Max 81mm |
| 41. | ZC16X01800 | [4] | CLIP | KOBClamp, Hose -- Min 12 x Max 22mm |
| 43. | YN21PU1003P1 | [1] | HYD CONNECTOR | KOBELBOW |
| 44. | ZE82T12000 | [1] | PLUG | KOB3/4" PT |
| 45. | 2444T3956 | [1] | ADAPTER | KOB |
| 46. | 2479R2365 | [1] | INSULATOR | KOB |
| 47. | YW12PU1004D1 | [1] | CLAMP,70mm - 81.8mm | KOB |
| 48. | 2432R225D10 | [1] | CLIP | KOBClamp, Single -- ID 25.5 x 58.75mm Long Superseded by part number: ZC46X25011 |
| 49. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 50. | ZS18C12025 | [4] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 51. | YW02P01002P1 | [2] | RUBBER | KOBMOUNT Superseded by part number: YW02P01002P2 |
| 52. | YW02P01003P1 | [2] | ENGINE MOUNT | KOB Superseded by part number: YW02P01003P2 |
| 53. | YW02P01004P1 | [4] | ENGINE MOUNT | KOBRUBBER |
| 54. | ZS18C08025 | [4] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 55. | 2444R2492D225 | [1] | FLEXIBLE HOSE | KOB |
| 56. | NSS | [8] | NOT SOLD SEPARAT | CONCAPSCREW |
| 57. | ZS18C10025 | [10] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 58. | ZS18C16035 | [4] | SCREW,Hex, M16 x 35mm | KOBM16x2.0x35mm |
| 59. | ZS18C10020 | [10] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 60. | ZC16X05100 | [1] | CLIP | KOBClamp, Hose -- Min 40 x Max 61mm |
| 61. | ZN18C08007 | [8] | NUT | KOBM08x1.25mm |
| 62. | NSS | [1] | NOT SOLD SEPARAT | CONGUARD FAN (RADIATOR PART) |
| 63. | ZN13C18015 | [4] | NUT | KOBM18x2.5mm |
| 64. | ZW26X10000 | [21] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 65. | ZW16H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 66. | ZW16H12000 | [24] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 67. | 2479R2318 | [1] | INSULATOR | KOB |
| 69. | 2479R2364 | [1] | INSULATOR | KOB |
| 70. | ZS13C12032 | [6] | CAPSCREW M12x1.75x32mm | CAPSCREW M12x1.75x32mm |
| 71. | 2415Z194D2 | [2] | BAND | KOB |
| 72. | 2432Z290D3 | [12] | CLIP | KOBWire Ties -- 154mm Long Superseded by part number: PY01P01043D3 |
| 73. | 2418Z1333D6 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1400mm Length | KOB |
| 74. | 2418Z1333D7 | [2] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1000mm Length | HIT |
| 75. | 2418Z1333D1 | [2] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 250mm Length | KOBProtective Plastic |
| 76. | 2414P9843 | [1] | COVER | KOB |
| 77. | 2416N7200 | [1] | U-BRACKET | KOB Superseded by part number: 2416N7972, 77252177 |
| 78. | ZW16H10000 | [17] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 79. | ZS13C12045 | [4] | SCREW | KOBM12x1.75x45mm Superseded by part number: ZS18C12045 |
| 80. | ZW26X12000 | [6] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 81. | ZS18C10016 | [1] | SCREW,Hex, M10 x 16mm | KOBM10x1.50x16mm |
| 82. | ZC16X02400 | [1] | CLIP | KOB |
| 83. | 2479Z2954 | [1] | INSULATOR | KOB |
| 84. | 24100N8651F1 | [1] | STARTING AID INSTAL, REF : 05-005 | |
| 85. | YN02PU1001P1 | [1] | SPARE PART | HITFAN Superseded by part number: VW3912753 |
| 86. | ZS18C10100 | [4] | SCREW,Hex, M10 x 100mm | KOBM10x1.50x100mm |
| 87. | NSS | [4] | NOT SOLD SEPARAT | CONFANSPACER (ENGINE PART) |
| 88. | NSS | [1] | NOT SOLD SEPARAT | CONFANSPACER (ENGINE PART) |
| 89. | YN02PU1003P1 | [1] | TEMPERATURE SWITCH,105 Degrees C, 221 Degrees F | KOBSWITCH, THERMO Superseded by part number: VW3408627 |
| 90. | 2446R277F2 | [1] | AIR CLEANER | KOB |
| 90-1. | 2446R254S1 | [1] | NUT | KOBWING |
| 90-2. | 2446R254S2 | [1] | RING | KOBE-RING |
| 90-3. | 2446R254S3 | [1] | NUT | KOBWING |
| 90-4. | 2446R254S4 | [1] | WASHER | KOBSEAL |
| 90-5. | 2446R277S5 | [1] | AIR FILTER | KOBOUTER |
| 90-7. | 2446R255S7 | [1] | EJECTOR | KOBVALVE |
| 91. | ZS18C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 92. | 2420R1126R100 | [1] | PLUG,M18 x 1.5 | KOBASSY |
