现代零件查询110/130/140/160D-7E FORK GROUP(SLIDING TYPE, 140/160D-7E)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
854 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
67FT-76800
|
[2] |
FORK WA(1350)
|
|
| 1. |
67FT-76900
|
[2] |
FORK WA(1500)
|
|
| 1. |
67FT-76900
|
[2] |
FORK WA(1500)
|
|
| 1. |
67FT-77100
|
[2] |
FORK WA(1800)
|
|
| 1. |
67FT-77200
|
[2] |
FORK WA(2100)
|
|
| 1. |
67FT-77300
|
[2] |
FORK WA(2440)
|
|
| 2. |
61FT-73000
|
[8] |
ROLLER ASSY
|
|
| 2. |
61FT-73001
|
[8] |
ROLLER ASSY
|
|
| 2. |
61FT-73002
|
[8] |
ROLLER ASSY
|
|
| 2. |
61FT-73000
|
[8] |
ROLLER ASSY
|
|
| 2. |
61FT-73001
|
[8] |
ROLLER ASSY
|
|
| 2. |
61FT-73002
|
[8] |
ROLLER ASSY
|
|
| 2-1. |
61FT-73010
|
[1] |
OUTER RACE(105)
|
|
| 2-2. |
61FT-73020
|
[1] |
SPHERICAL PLAIN BEARING
|
|
| 2-3. |
61FT-73030
|
[2] |
STOP RING
|
|
| 2-3. |
61FT-73030
|
[1] |
STOP RING
|
|
| 2-3. |
61FT-73030
|
[2] |
STOP RING
|
|
| 2-3. |
61FT-73030
|
[1] |
STOP RING
|
|
| 3. |
61FT-73500
|
[2] |
ROLLER ASSY
|
|
| 3. |
61FT-73501
|
[2] |
ROLLER ASSY
|
|
| 3. |
61FT-73502
|
[2] |
ROLLER ASSY
|
|
| 3. |
61FT-73500
|
[2] |
ROLLER ASSY
|
|
| 3. |
61FT-73501
|
[2] |
ROLLER ASSY
|
|
| 3. |
61FT-73502
|
[2] |
ROLLER ASSY
|
|
| 3-1. |
61FT-73510
|
[1] |
OUTER RACE(104.5)
|
|
| 3-2. |
61FT-73020
|
[1] |
SPHERICAL PLAIN BEARING
|
|
| 3-3. |
61FT-73030
|
[1] |
STOP RING
|
|
| 4. |
S601-050004
|
[10] |
RING-RETAINING
|
|
| 5. |
61FT-73100
|
[4] |
ROLLER ASSY(84)
|
|
| 5. |
61FT-73101
|
[4] |
ROLLER ASSY
|
|
| 5. |
61FT-73100
|
[4] |
ROLLER ASSY(84)
|
|
| 5. |
61FT-73101
|
[4] |
ROLLER ASSY
|
|
| 5. |
61FT-73200
|
[4] |
ROLLER ASSY(86)
|
|
| 5. |
61FT-73201
|
[4] |
ROLLER ASSY
|
|
| 5. |
61FT-73200
|
[4] |
ROLLER ASSY(86)
|
|
| 5. |
61FT-73201
|
[4] |
ROLLER ASSY
|
|
| 5. |
61FT-73300
|
[4] |
ROLLER ASSY(82)
|
|
| 5. |
61FT-73301
|
[4] |
ROLLER ASSY
|
|
| 5. |
61FT-73300
|
[4] |
ROLLER ASSY(82)
|
|
| 5. |
61FT-73301
|
[4] |
ROLLER ASSY
|
|
| 5-1. |
61FT-73110
|
[1] |
OUTER RACE(84)
|
|
| 5-1. |
61FT-73210
|
[1] |
OUTER RACE(86)
|
|
| 5-1. |
61FT-73220
|
[1] |
OUTER RACE(82)
|
|
| 5-2. |
61HS-73120
|
[2] |
BUSH
|
|
| 6. |
61FT-73400
|
[4] |
PIN
|
|
| 6. |
61FT-73700
|
[4] |
PIN ASSY
|
|
| 6. |
61FT-73400
|
[4] |
PIN
|
|
| 6. |
61FT-73700
|
[4] |
PIN ASSY
|
|
| 7. |
S112-100356
|
[8] |
SCREW-SET HEX SOCKET
|
|
| 8. |
61FT-73600
|
[2] |
BRACKET WA
|
|
| 9. |
S017-16045D
|
[8] |
BOLT-HEX
|
|
| 10. |
S411-160006
|
[8] |
WASHER-SPRING
|
|
| 11. |
S441-160006
|
[8] |
WASHER-HARDENED
|
|
| 12. |
S651-810008
|
[4] |
NIPPLE-GREASE
|
|
| 13. |
S652-810008
|
[10] |
NIPPLE-GREASE
|
|
