凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (04-001) - FRONT AXLE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
872 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
232-46410
|
[8] |
LOCK NUT
|
BN
5/8-18, TLN, CL 8
|
| 2. |
428-1036
|
[8] |
SCREW
|
CUR
5/8-18 X 2.25, HH, G8 Superseded by part number: 87342969
|
| 3. |
BN2303412
|
[8] |
LOCK WASHER
|
BN
3/8 Superseded by part number: 80680
|
| 4. |
BN321318
|
[2] |
FLANGED BEARING
|
BN
Flanged MSF-39
|
| 5. |
88011
|
[8] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
NH
|
| 6. |
BN7136046
|
[2] |
BEARING COVER
|
BN
Front Axle Bearing
|
| 7. |
BN7136030
|
[1] |
CENTER AXLE
|
TYR
Front Axle Assembly - 3/4 Stud, See Fig 04-002
|
