凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (04-007) - FRAME SUB ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1023 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2390250
|
[2] |
ROLLER BEARING
|
BN
48393
|
| 2. |
BN2390251
|
[2] |
BEARING CUP
|
BN
48320 Timken Superseded by part number: 47941920
|
| 3. |
BN2392060
|
[1] |
SEAL
|
BN
NATL 417780
|
| 4. |
BN2297214
|
[1] |
LOCK NUT
|
BN
AN-26 SKF4
|
| 5. |
BN2297215
|
[1] |
LOCK WASHER
|
BN
W-26 SKF
|
| 6. |
BN7131029
|
[1] |
COVER
|
BN
Front Fork Spindle
|
| 7. |
BN2296717
|
[1] |
GASKET
|
BN
7131039
|
| 8. |
9707580
|
[4] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
|
NH
|
| 9. |
80682
|
[4] |
LOCK WASHER,1/4"
|
PA
|
| 10. |
BN322588
|
[1] |
FORK
|
TYR
Weldment, Front
|
