凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (04-009) - 3-WHEEL STORAGE GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
965 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
9706687
|
[6] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 2. |
86625255
|
[12] |
WASHER,13.3mm ID x 24.5mm OD x 3mm Thk
|
GI
|
| 3. |
100038
|
[6] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 4. |
BN323193
|
[1] |
Group, Toolbox, See Fig 04-010
|
|
| 5. |
BN323196
|
[2] |
BRACKET
|
BN
3 Wheel Toolbox
|
| 6. |
BN321104
|
[1] |
SUPPORT
|
BN
Brace, 3 Wheel Toolbox
|
| 8. |
BN63818
|
[4] |
WASHER,20.57mm ID x 69.85mm OD x 4.76mm Thk
|
BN
7 GA 304 .81 x 2.75
|
| 9. |
832-46424
|
[4] |
NUT,M24 x 3, Cl 8
|
CAS
Superseded by part number: 589418
|
| 10. |
86509867
|
[6] |
BOLT,Hex Flg, M16 x 40mm
|
WIN
|
| 11. |
86625266
|
[4] |
WASHER,17.5mm ID x 30mm OD x 4mm Thk
|
GI
|
| 12. |
832-46416
|
[6] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 13. |
A181434
|
[1] |
SUPPORT
|
CAS
Mount, Toolbox
|
| 14. |
A181436
|
[1] |
TOOL BOX
|
CAS
Steel
|
