凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (10-012) - BED MOUNT HARDWARE, N-LEADER, 13' Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
696 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN21533
|
[2] |
EYEBOLT
|
BN
BOLT, EYE 3/4"-10 x 8
|
| 2. |
BN2390533
|
[2] |
EYEBOLT
|
BN
3013T69, 3/4 X 3"
|
| 3. |
BN2397999
|
[2] |
SPRING
|
BN
2 X 1 ID MHP-85
|
| 4. |
86986947
|
[4] |
PIN,28.7mm OD x 76.45mm L
|
BN
1.125 Dia. x 2.625
|
| 5. |
BN2297612
|
[4] |
PIN
|
BN
Clip 3/16" Dia x 3 3/4"
|
| 6. |
86632591
|
[6] |
WASHER,0.81" ID x 1.5" OD x 0.13" Thk
|
FOR
Superseded by part number: 394632
|
| 7. |
98066
|
[2] |
|
NUT 3/4"-10, G5
|
| 8. |
280375
|
[4] |
NUT,3/4"-10, GC
|
WIN
|
