| . . | 24100J15093F8 | [1] | ARM ASSY, 2.5M (8 FT-2 IN) (EXTRA) | |
| 2. | 2438U1131F1 | [1] | CYLINDER | KOBFF:SEE(C.P.M) |
| 3. | 2406N795F1 | [1] | LINK CONROD | KOB |
| 3-6. | 2405T825 | [2] | BUSHING | KOBID 65 x OD 80 x 60mm Long |
| 3-7. | 2405T824 | [2] | BUSHING | KOBID 60 x OD 75 x 69mm Long |
| 4. | 2406P4866D2 | [1] | LINK CONROD | KOBIDLER |
| 5. | 2406P4866D1 | [1] | LINK CONROD | KOBIDLER |
| 9. | 2444R1169D3 | [2] | FLEXIBLE HOSE,6.35mm ID x 1200mm L | KOB1200mm Long (47-1/4in) |
| 10. | 2419P1643 | [2] | PIN | KOB |
| 11. | 2419P3416D2 | [1] | PIN | KOBOD 60 x 377mm Long |
| 12. | 2419P3417D2 | [1] | PIN,60mm OD x 377mm L | KOBOD 60 x 377mm Long |
| 13. | 2419P3229 | [1] | PIN | KOB Superseded by part number: 2419P4370 |
| 14. | 2419P3228D2 | [1] | PIN | KOBOD 60 x 164mm Long Superseded by part number: 2419P4042D2 |
| 15. | 2445R220D2 | [4] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOBDust -- ID 65 x OD 80 x Th 5mm Superseded by part number: 84499663 |
| 16. | 2445R138D6 | [2] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| 17. | 2445R138D3 | [6] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| 18. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 20. | 2432T1333 | [1] | CLAMP | KOBSingle Block -- 50x30x25mm Superseded by part number: YW43H01049P1 |
| 21. | 2420T4327D5 | [2] | SCREW,M14 x 2 x 115mm | KOBSCREW |
| 22. | 2420T4331D6 | [1] | CAPSCREW M12x1.75x110mm | CAPSCREW M12x1.75x110mm |
| 23. | ZS13C10060 | [8] | SCREW | KOBM10x1.50x60mm Superseded by part number: ZS18C10060 |
| 24. | ZS13C10050 | [1] | SCREW | KOBM10x1.50x50mm Superseded by part number: ZS18C10050 |
| 25. | ZN13C14011 | [4] | NUT | KOBM14x2.0mm Superseded by part number: ZN18C14011 |
| 26. | ZN13C12010 | [4] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 27. | ZW22X10000 | [9] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 28. | ZG91U02000 | [2] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 29. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 30. | B16T0442D1 | [1] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| 31. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 32. | B16T0442D5 | [1] | SHIM,130mm OD x 72mm ID x 2.3mm Thk | KOBID 72 x OD 130 x Th 2.3mm |
| 33. | B16T0442D27 | [4] | SHIM,62mm ID x 100mm OD x 1.2mm Thk | KOBID 62 x OD 100 x Th 1.2mm |
| 34. | B16T0442D19 | [4] | SHIM,62mm ID x 100mm OD x 1.6mm Thk | KOBID 62 x OD 100 x Th 1.6mm |
| 35. | B16T0442D20 | [4] | SHIM,100mm OD x 62mm ID x 2.3mm Thk | KOBID 62 x OD 100 x Th 2.3mm |
| 36. | 2418T23986D1 | [2] | RING | KOBID 94 x OD 98 x Th 12mm |
| 37. | 2419T6002D7 | [2] | PIN,14mm OD x 91mm L | KOBOD 14 x 91mm Long |
| 45. | 2420T4331D1 | [1] | SCREW,M12 x 1.75 x 125mm | KOBM12x1.75x125mm |
| 46. | B16T0442D43 | [4] | SHIM,62mm ID x 100mm OD x 0.9mm Thk | KOBID 62 x OD 100 x Th 0.9mm |
| 47. | B16T0442D56 | [4] | SHIM,62mm ID x 100mm OD x 0.5mm Thk | KOBID 62 x OD 100 x Th 0.5mm |
| 48. | B16T0442D44 | [1] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOBID 72 x OD 130 x Th 0.9mm |
| 49. | B16T0442D57 | [1] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOBID 72 x OD 130 x Th 0.5mm |
| 50. | B16T0442D88 | [1] | SHIM,100mm OD x 67mm ID x 0.5mm Thk | KOBID 67 x OD 100 x Th 0.5mm |
| 53. | 2418P31221 | [1] | RIGID TUBE | KOB Superseded by part number: 2418P10046D2 |
| 54. | 2418P31222 | [1] | RIGID TUBE | KOB Superseded by part number: 2418P22119 |
| 113. | ZW22X08000 | [7] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 210. | ZC36X15009 | [3] | CLAMP | KOB |
| 211. | ZA53B15000 | [2] | TEE | KOB |
| 212. | 2420T4384 | [4] | PLUG | KOB |
| 213. | 2444Z2222 | [4] | HYD CONNECTOR | KOB |
| 300. | 2411J4696D5F1 | [1] | ARM | |
| 300-20. | 2405P472 | [2] | BUSHING | KOBID 65 x OD 80 x 75mm Long, Flange OD 130 |
| 300-21. | 2405T824 | [2] | BUSHING | KOBID 60 x OD 75 x 69mm Long |
| 300-22. | 2405T823 | [2] | BUSHING | KOBID 70 x OD 85 x 70mm Long |
| 300-30. | 2416T10838 | [3] | CONNECTING BLOCK | KOBTAPPED |
| 300-31. | 2416T11053 | [2] | PLATE | KOB |
| 301. | 2418T16837 | [1] | TUBE | |
| 302. | 2418T16836 | [1] | TUBE | |
| 303. | 2418T12732 | [1] | TUBE | KOBTUBE |
| 304. | 2418T12733 | [1] | TUBE | KOBTUBE |
| 305. | 2418P19074 | [1] | TUBE | |
| 306. | 2418P23769 | [1] | TUBE | |
| 307. | 2432T1773 | [4] | CLAMP | KOB |
| 308. | ZS13C08038 | [7] | SCREW | KOBM08x1.25x38mm Superseded by part number: ZS18C08040 |
| 309. | ZX56N08130 | [2] | HOSE 1300mm Long (51-3/16 in) | HOSE 1300mm Long (51-3/16 in) |
