凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (05-002[03]) - FRONT TIRE GROUP - 66" FIRESTONE, 10 PLY, TIRE-MTD LH, 66X43, 10PL, FS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
814 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2395033
|
[1] |
Tire, 66/4300-25 10 PLY
|
|
| 2. |
BN311818
|
[1] |
WHEEL ASSY
|
TYR
Rear, Weldment
|
| 2A. |
BN2391858
|
[1] |
O-RING
|
BN
OR25T Black
|
| 2B. |
BN67197
|
[1] |
VALVE STEM
|
BN
TR-600
|
| 2C. |
BN2297235
|
[1] |
LOCKING RING
|
BN
LR25T
|
| 2D. |
BN2396615
|
[1] |
FLANGE
|
TYR
FL025T
|
| 2E. |
BN324007
|
[1] |
DECAL
|
BN
Torque Wheel Nuts
|
