凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (02-001[02]) - ENGINE GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
153 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2290298
|
[2] |
BUSHING
|
BN
0102-12-6
|
| 2. |
BN2292249
|
[2] |
HYDRAULIC VALVE
|
BN
Heater Everhot
|
| 3. |
BN2394965
|
[1] |
TEMPERATURE SENDER
|
BN
02025-00-1/2
|
| 4. |
BN314865
|
[1] |
Alternator Group, 300 CDC
|
|
| 5. |
BN314866
|
[1] |
Starter Group, 300 CDC
|
|
| 6. |
BN318784
|
[1] |
Air Compressor Group
|
|
| 6A. |
BN318785
|
[1] |
Coolant Lines, Air Comp
|
|
| 6B. |
BN318786
|
[1] |
Air Intake Tube, Air Comp
|
|
| 6C. |
BN318787
|
[1] |
Air Compressor Assembly
|
|
| 7. |
BN318816
|
[1] |
SENDER UNIT
|
BN
Oil Pressure Superseded by part number: BN319998
|
| 8. |
BN319006
|
[1] |
Turbo Elbow Group
|
|
| 8A. |
J008465
|
[2] |
PLUG
|
L
1/8 NPT, INT Hex, Seal Superseded by part number: J008465AM
|
| 8B. |
J883284
|
[1] |
O-RING,0.07" Thk x 2.364" ID, -36
|
CAS
Seal Superseded by part number: J883284AM
|
| 8C. |
J883977
|
[1] |
ELBOW
|
CAS
Turbo X 4, 90 Degree
|
| 8D. |
J923041
|
[1] |
SLOTTED NUT
|
TYR
|
| 8E. |
J923060
|
[1] |
CLAMP,76.2mm
|
TYR
Superseded by part number: J069053
|
| 9. |
BN319293
|
[1] |
O-RING
|
BN
Plug, M22 Hex Head (Not Visible)
|
| 10. |
381813A1
|
[1] |
Engine, Case 8.3L, 300HP
|
|
| 11. |
BN75978
|
[2] |
HOSE CLAMP
|
BN
SS - #12 ADJ HS .56-1.25 Superseded by part number: BN310446
|
| 12. |
BN321445
|
[1] |
THERMOSTAT
|
BN
300HP QSC Mode Superseded by part number: 84427136
|
| 13. |
BN321949
|
[1] |
PLATE
|
BN
Hose Guard
|
| 14. |
BN444008
|
[1] |
FITTING
|
BN
8MJ 10MB
|
| 15. |
86625038
|
[1] |
CLAMP,25.4mm, Coat, 13.5mm Bolt Hole, P Type
|
FAR
|
| 16. |
BN51499
|
[1] |
8FP-16MP (Not Visible)
|
|
| 17. |
BN53594
|
[1] |
FITTING
|
BN
8MJ-8MBx90
|
