凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (02-003) - ENGINE MOUNTING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
230 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87529240
|
[16] |
WASHER,0.53" ID x 1.06" OD x 0.13" Thk
|
BN
0.531 x 1.062 x 0.134 HTS DOR HDN
|
| 2. |
100037
|
[4] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 3. |
87848
|
[16] |
BOLT,Hex, 1/2" - 20 x 1", Gr 5
|
GI
|
| 4. |
11106231
|
[4] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9
|
LEC
|
| 5. |
86512555
|
[5] |
NUT,M16 x 2, Cl 10
|
FOR
|
| 6. |
BN300501
|
[6] |
WASHER
|
BN
M16, FW, 10.9 Superseded by part number: 896-15016
|
| 7. |
86639145
|
[2] |
BOLT,Hex, M20 x 130mm, Cl 10.9
|
FAR
|
| 8. |
BN306728
|
[2] |
ENGINE MOUNT
|
BN
|
| 9. |
BN308164
|
[2] |
WASHER
|
BN
Rebound
|
| 10. |
BN314556
|
[1] |
MOUNTING PLATE
|
BN
Front Engine/Frame, RS
|
| 11. |
BN314557
|
[1] |
MOUNTING PLATE
|
BN
Front Engine/Frame, CS
|
| 12. |
342751A1
|
[1] |
MOUNTING PLATE
|
BN
rear engine/frame
|
| 13. |
342750A1
|
[1] |
MOUNTING PLATE
|
BN
rear engine/frame
|
| 14. |
BN324981
|
[2] |
ENGINE MOUNT
|
BN
|
| 15. |
BN314568
|
[1] |
CROSSRAIL
|
BN
Crossmember, Engine
|
| 16. |
614-12035
|
[8] |
BOLT,Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd
|
IH
|
| 17. |
BN300500
|
[8] |
WASHER,M12, 10.9
|
BN
Superseded by part number: 86625255
|
| 18. |
120092
|
[3] |
BOLT,M16 x 70mm, Cl 8.8
|
NH
|
| 19. |
BN318560
|
[1] |
BRACKET
|
BN
Bracket, Turbo Tube
|
| 20. |
43281
|
[2] |
BOLT,Hex, M16 x 2 x 120mm, Cl 10.9
|
GI
|
| 22. |
BN50155
|
[2] |
WASHER,17.48mm ID x 44.45mm OD x 3.05mm Thk
|
BN
5/8", G5
|
| 23. |
BN324263
|
[2] |
MOUNTING PLATE
|
BN
535 Rear Engine
|
| 24. |
BN322925
|
[2] |
WASHER
|
BN
Rebound M20
|
| 25. |
832-10420
|
[2] |
NUT,M20 x 2.5, Cl 8
|
CAS
Superseded by part number: 9672396
|
| 26. |
86625260
|
[2] |
WASHER,21.8mm ID x 37.5mm OD x 4mm Thk
|
FAR
|
| 27. |
43260
|
[4] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 10.9, Full Thd
|
BHB
|
| 28. |
100038
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
