凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (02-006) - AIR COMPRESSOR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
957 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
J680997
|
[1] |
UNION
|
TYR
Male
|
| 2. |
J900634
|
[2] |
FLANGE BOLT,Hvy Hex, M10 x 50mm, Cl 10.9
|
CAS
Superseded by part number: 87522185
|
| 3. |
854-10030
|
[4] |
BOLT,Hvy Hex, M10 x 30mm, Cl 10.9
|
CAS
Superseded by part number: 87778358
|
| 4. |
J906747
|
[1] |
HOSE,6.35mm ID x 508mm L
|
CAS
Flexible, Oil Line, Not Shown
|
| 5. |
J920447
|
[2] |
FLANGE BOLT,M12 x 40mm, Cl 10.9
|
BHB
Bolt-Flange, M12 X 40, 10.9 Superseded by part number: 75287983
|
| 6. |
J940245
|
[1] |
GASKET,1.27mm Thk
|
CAS
Hydraulic Superseded by part number: J940245AM
|
| 7. |
J942911
|
[1] |
BRACKET
|
TYR
Air Compressor Brace Superseded by part number: 87573590
|
| 8. |
J944000
|
[1] |
SPACER
|
TYR
Mounting Superseded by part number: 87573589
|
| 9. |
J949098
|
[1] |
AIR COMPRESSOR
|
TYR
18.7 CFM Superseded by part number: 84157546
|
| 10. |
J945212
|
[2] |
ELBOW
|
RAC
Plain Union (Not Shown)
|
