凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (02-012) - AIR FILTER GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
138 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN322270
|
[1] |
BRACKET
|
BN
Air Filter
|
| 2. |
43140
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 3. |
BN300499
|
[8] |
WASHER,M10, 10.9
|
BN
Superseded by part number: 896-11010
|
| 4. |
100037
|
[4] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 5. |
86050212
|
[4] |
BOLT,Hex, 7/16" - 14 x 1 1/2", Gr 8
|
WIN
|
| 6. |
86637952
|
[4] |
WASHER,0.47" ID x 0.92" OD x 0.07" Thk
|
FAR
0.469 x 0.922 x 0.065, Hardened
|
| 7. |
BN310649
|
[1] |
PACKAGE
|
BN
Filter, Aircleaner Assembly
|
| 7A. |
90-8299T91
|
[1] |
AIR CLEANER
|
L
Assembly
|
| 7B. |
90-8300T1
|
[1] |
AIR FILTER
|
L
Primary
|
| 7C. |
90-8301T1
|
[1] |
AIR FILTER
|
L
Safety
|
| 7D. |
90-8302T1
|
[1] |
COVER
|
L
Assembly
|
| 7E. |
BN312976
|
[1] |
PRECLEANER
|
BN
Assembly
|
| 7F. |
BN312977
|
[1] |
ADAPTER
|
BN
|
| 7G. |
BN312978
|
[1] |
CLAMP
|
BN
Assembly
|
| 7H. |
BN9-120
|
[1] |
CAP
|
BN
Assembly Superseded by part number: 70197576
|
| 7J. |
S219931
|
[1] |
CLAMP
|
CAS
Band Assembly, Mounting Superseded by part number: 90-3871T1
|
| 8. |
BN76084
|
[2] |
HOSE CLAMP
|
BN
Adj. #24, SS Superseded by part number: 87485002
|
| 9. |
BN306562
|
[1] |
HOSE,1.50" ID x 42.00"
|
BN
1.5 TPE x 42"
|
| 10. |
BN2399320
|
[1] |
CLAMP
|
BN
Loom, Del City #2032
|
| 11. |
BN2396358
|
[2] |
CLAMP
|
BN
T-Bolt Band 7"
|
| 12. |
BN2390854
|
[1] |
HOSE
|
BN
Hump, 7 To 7
|
| 13. |
BN303501
|
[1] |
FILTER
|
BN
Minder Kit
|
| 14. |
BN302813
|
[1] |
PIPE
|
BN
Air Intake Riser Superseded by part number: 84492074
|
| 15. |
BN322568
|
[1] |
SUPPORT
|
BN
Tube, Air Cleaner
|
| 16. |
86528579
|
[2] |
NUT,M8 x 1.25
|
WIN
|
| 17. |
BN300497
|
[4] |
WASHER,M8, 10.9
|
BN
Superseded by part number: 896-15008
|
| 18. |
43128
|
[2] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 19. |
280641
|
[3] |
BOLT,Hex, 1/4" - 20 x 5/8", Gr 5
|
BAS
|
| 20. |
87529236
|
[3] |
WASHER,0.28" ID x 0.62" OD x 0.07" Thk
|
BN
0.281 X 0.625 X 0.065 HTS DOR HDN
|
