神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (12-040) - MANIFOLD ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
597 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U2756F1 | [1] | MANIFOLD ASSY | MANIFOLD ASSY |
| . . | 2436U2756F3 | [1] | MANIFOLD | KOB |
| 1. | 2436R914S1 | [1] | BLOCK | KOB |
| 2. | 2446R351F1 | [1] | FILTER | KOBASSY |
| 2-1. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 2-2. | NSS | [1] | NOT SOLD SEPARAT | CONCAP |
| 2-3. | NSS | [1] | NOT SOLD SEPARAT | CONSCREEN |
| 2-4. | ZD11P02800 | [1] | O-RING | KOBID 27.70 ± 0.28 x OD 34mm |
| 2-5. | 2446R351S5 | [1] | O-RING | KOB |
| 3. | 2436R940F1 | [1] | VALVE | KOBASSY |
| 3-1. | 2436R940S1 | [1] | BACK-UP RING | KOB |
| 3-2. | 2436R940S2 | [1] | O-RING | KOB |
| 3-3. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET |
| 3-4. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 3-5. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING |
| 3-6. | 2436R940S6 | [1] | O-RING | KOB |
| 3-7. | NSS | [1] | NOT SOLD SEPARAT | CONRETAINER |
| 4. | 2436R943F1 | [1] | VALVE | KOBASSY (FOR F1 ONLY) Superseded by part number: 2436R943F2 |
| 4-1. | 2436R940S2 | [1] | O-RING | KOB(FOR F1 ONLY) |
| 4-2. | 2436R940S1 | [1] | BACK-UP RING | KOB(FOR F1 ONLY) |
| 4-3. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET (FOR F1 ONLY) |
| 4-4. | NSS | [1] | NOT SOLD SEPARAT | CONBODY (FOR F1 ONLY) |
| 4-5. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING (FOR F1 ONLY) |
| 4-6. | 2436R940S6 | [1] | O-RING | KOB(FOR F1 ONLY) |
| 4-7. | NSS | [1] | NOT SOLD SEPARAT | CONRETAINER ASSY (FOR F1 ONLY) |
| 5. | 2436R941F1 | [1] | VALVE | KOBASSY |
| 5-1. | 2436R940S1 | [1] | BACK-UP RING | KOB |
| 5-2. | 2436R940S2 | [1] | O-RING | KOB |
| 5-3. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET |
| 5-4. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 5-5. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING |
| 5-6. | 2436R940S6 | [1] | O-RING | KOB |
| 5-7. | NSS | [1] | NOT SOLD SEPARAT | CONRETAINER |
| 6. | 2436U2756S6 | [1] | PLUG ASSY (FOR F1 ONLY) | |
| 7. | 2436U2756S7 | [1] | PLUG ASSY | |
| 8. | ZE72X08000 | [1] | PLUG | KOB1/2" PF, (Incls. O-Ring ZD12P01800), (FOR F3 Only) |
| 9. | 2436R943F2 | [1] | VALVE | KOBASSY, RELIEF (FOR F3 ONLY) |
| 9-1. | 2436R940S2 | [1] | O-RING | KOB(FOR F3 ONLY) |
| 9-2. | 2436R940S1 | [1] | BACK-UP RING | KOB(FOR F3 ONLY) |
| 9-5. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING (FOR F3 ONLY) |
| 9-6. | 2436R940S6 | [1] | O-RING | KOB(FOR F3 ONLY) |
| 9-8. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET (FOR F3 ONLY) |
| 9-9. | NSS | [1] | NOT SOLD SEPARAT | CONBODY (FOR F3 ONLY) |
| 9-10. | NSS | [1] | NOT SOLD SEPARAT | CONRETAINER ASSY (FOR F3 ONLY) |
| . . | 2436R940R100 | [1] | SEAL KIT | KOBCONSISTS OF REF 3-1, 3-2, 3-6, 4-1, 4-2, 4-6, 5-1, 5-2, 5-6 (FOR F1 ONLY) |
| . . | 2436R940R200 | [1] | SEAL KIT | KOBCONSISTS OF REF 3-3, 3-5, 3-7 |
