神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (09-006) - ROCKER COVER AND BREATHER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
346 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 01100. | VAME014656 | [1] | COVER | KOBCOVER, ROCKER, FROM-UP TO: 0001.1-, MODEL TYPE: ALL Superseded by part number: VAME229391 |
| 01110. | VAME011279 | [1] | GASKET | KOBGASKET, ROCKER COVER, FROM-UP TO: 0001.1-, MODEL TYPE: ALL |
| 01134. | VAME011282 | [2] | RUBBER SLEEVE | KOBSEAL, ROCKER COVER BOLT, FROM-UP TO: 0001.1-, MODEL TYPE: ALL, Remarks: RUBBER |
| 01182B. | VAME011281 | [2] | PLATE | KOBWASHER, ROCKER COVER, FROM-UP TO: 0001.1-, MODEL TYPE: ALL, Remarks: 8.5 |
| 01198B. | VAMF104864 | [2] | BOLT | KOBBOLT, ROCKER COVER, FROM-UP TO: 0001.1-, MODEL TYPE: ALL, Remarks: 8X45 |
| 01951. | VAME217057 | [1] | HOSE | KOBHOSE, ENG BREATHER, FROM-UP TO: 0001.1-, MODEL TYPE: ALL |
| 01987. | VAMH021352 | [1] | CLIP | KOBCLIP, ENG BREATHER, FROM-UP TO: 0001.1-, MODEL TYPE: ALL, Remarks: D=49 |
| 04903A. | VAMD008784 | [1] | CAP | KOBCAP ASSY, ENG OIL FILLER, FROM-UP TO: 0001.1-, MODEL TYPE: ALL Superseded by part number: VA1250A015 |
