| 0. |
A77970
|
[6] |
PISTON & RINGS KIT
|
CAS
Standard
|
| 1. |
J948095
|
[1] |
SLEEVE CYLINDER,114.02mm ID x 130.95mm OD x 234.12mm L
|
CAS
|
| 2. |
J907177
|
[1] |
SEAL,118mm ID x 122.32mm OD x 4mm Thk
|
IH
Sealing
|
| 2A. |
J800320
|
[1] |
PISTON & RINGS KIT
|
CAS
With Rings, Standard, Contains Ref. 3 & 5
|
| 3. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Piston
|
| 4. |
100-21175
|
[2] |
SNAP RING,1.75", Int, #175
|
CAS
Superseded by part number: 66967
|
| 5. |
J802538
|
[1] |
PISTON RINGS KIT
|
CAS
Standard
|
| 9. |
J934046
|
[6] |
PISTON PIN,45mm OD x 91mm L
|
CAS
|
| 9A. |
J924445
|
[1] |
SHIM,126.8mm ID x 130.5mm OD x 0.25mm Thk
|
CAS
|
| 9A. |
J924446
|
[1] |
SHIM,126.8mm ID x 130.5mm OD x 0.38mm Thk
|
CAS
|
| 9A. |
J924447
|
[1] |
SHIM,126.8mm ID x 130.5mm OD x 0.5mm Thk
|
CAS
|
| 9A. |
J924448
|
[1] |
SHIM,0.762mm Thk
|
CAS
|
| 9A. |
J924449
|
[1] |
SHIM,1.000mm Thk
|
CAS
|
| 9B. |
JR901383
|
[6] |
REMAN-CONNECTING ROD
|
CAS
Assembly, North America Only, Component Parts Shown On This Page Do Not Apply To The Remanufactured Assembly Superseded by part number: 84487529R
|
| 9C. |
JC901383
|
[1] |
CORE-ROD CONNECTING
|
CAS
CORE-CONNECTING ROD Return Number - Use This Part Number To Return Connecting Rod For Credit When Using A Remanufactured Assembly Superseded by part number: 84145656C
|
| 9D. |
J901383
|
[6] |
CONNECTING ROD
|
IH
Assembly Superseded by part number: 84487529
|
| . . |
84487529R
|
[6] |
REMAN-CONNECTING ROD
|
BUR
FLX3300B (9/02 - 10/03), Reman for New P/N J901383
|
| . . |
84487529C
|
[1] |
CORE-ROD CONNECTING
|
BUR
Return Number
|
| 12. |
J913990
|
[1] |
BUSHING,45.03mm ID x 49mm OD x 45mm L
|
CAS
Connecting Rod Superseded by part number: 87343250
|
| 13. |
J928870
|
[2] |
ROD
|
CAS
connecting rod
|
| 14. |
J934864
|
[2] |
NUT
|
CAS
Hex, Rod Bolt
|
| 15. |
87443389
|
[6] |
BEARING LINER
|
BRR
Kit - Upper And Lower, Standard
|
| 15. |
87443529
|
[6] |
BEARING LINER
|
CAS
Kit - Upper And Lower, 0.25 mm Undersize Superseded by part number: 84156219
|
| 15. |
A77565
|
[6] |
BEARING SET
|
IH
Kit - Connecting Rod, 0.50 mm Undersize Superseded by part number: 84156220
|
| 15. |
84156221
|
[6] |
BEARING SET
|
CAS
Kit - Upper and Lower, 0.75 mm Undersize
|
| 15. |
87443534
|
[6] |
BEARING LINER
|
CAS
Kit - Connector Rod, 1.00 mm Undersize Superseded by part number: 84156222
|
